5.7.1 Status indication

About router status inform four LED indicators on the front panel. ETH port, PORT1 and
PORT2 have two additional LEDs that provide information about port status.
Caption Color
PWR Green
USR Yellow
OUT Green
IN Green
ETH Green
ETH Yellow
PORT Green
PORT Yellow
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
State Description
Blinking Router is ready
On Starting of the router
Fast blinking Updating firmware
Function of this LED diode can be selected by user
On Binary output active
On Binary input active
On Selected 100 Mbit/s
Off Selected 10 Mbit/s
On The network cable is connected
Blinking Data transmission
Off The network cable is not connected
Depends on the expansion port (see user's manual for used port)
Depends on the expansion port (see user's manual for used port)
Table 5: Status indication
