Summary of Contents for Da-Lite Designer Manual
- Page 1 INSTRUCTION BOOK FOR Designer Manual...
- Page 2 For Wall Mounting Hardware Provided (2) “V” Bars ( one is factory mounted to the back of the case; one will be mounted to the wall) (6) Toggle Bolts, 4" (6) Lead Shields, #10-14 x 1-1/2" (6) Phillips Flat Head Wood Screws, #10 x 2" Tools Required Electric Drill Masonry Bit 5/16"...
- Page 3 Installation Instructions Maintenance Projection Screen Maintenance Determine the height of the top of the case from the floor. This will be the height of the wall mounted “V” bar. Protect your screen by keeping it rolled in its case when not in use.
- Page 4 OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
