The
POWER
In
PRESENTATION PRODUCTS
DA-LITE SCREEN COMPANY, INC.
Instruction Book for
3100 North Detroit Street
Post Office Box 137
Warsaw, Indiana 46581-0137
®
DIRECTOR ELECTROL
Phone: 574-267-8101
800-622-3737
Fax: 574-267-7804
Toll Free Fax: 877-325-4832
www.da-lite.com
e-mail: info@da-lite.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIRECTOR ELECTROL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Da-Lite DIRECTOR ELECTROL

Summary of Contents for Da-Lite DIRECTOR ELECTROL

  • Page 1 POWER PRESENTATION PRODUCTS DA-LITE SCREEN COMPANY, INC. Instruction Book for 3100 North Detroit Street Post Office Box 137 Warsaw, Indiana 46581-0137 ® DIRECTOR ELECTROL Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 Toll Free Fax: 877-325-4832 www.da-lite.com e-mail: info@da-lite.com...

  • Page 2: Important Safety Instructions

    5. Install electric hook up that applies to your unit. Make sure to review your electrical installation checklist and wiring diagram (included) for either 120 volt switch, 220/240 volt switch, or DRC low voltage control. NOTE: Screen has been internally wired at Da-Lite. Wiring designated “external” is completed by installer conforming to local and national codes.

  • Page 3: Access Door Installation

    Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly adjusted at Da-Lite. Should it be necessary to adjust for more or less drop of picture, proceed in the following manner: NOTE: Use a screw driver or 5/32" Allen wrench to make adjustments.
  • Page 4 2. Place operating switch in “off”position. 3. Turn the white “down” limit switch (Fig. 2) one-quarter turn clockwise. Test by raising picture surface approximately two feet, then lower again. Repeat until desired picture surface position is attained. DIRECTOR ELECTROL ® INSTRUCTIONS...

  • Page 5: Wiring Diagram

    DIRECTOR ELECTROL INSTRUCTIONS ® NOTE: Electrical connections on left end of case. RED (UP) BLACK BLACK (DOWN) WHITE 120V WIRING DIAGRAM GRAY GREEN WHITE BLACK & YELLOW BLACK TO JUNCTION BOX MOUNTED IN SCREEN CASE, IN WHICH INTERNAL WIRING TERMI-...
  • Page 6 DIRECTOR ELECTROL ® INSTALLATION 7-1/4" 7-1/4" VARIABLE POSITION CASE LENGTH MOUNTING BRACKETS 6-1/8" FLAT BRACKET MOUNTING METHOD MOTOR END 9-1/4" ELECTRICAL JUNCTION BOX 6-1/8" (SUGGESTED) 3/8" THREADED ROD (NOT INCLUDED) ATTACHED TO MOUNTING BRACKET 7-1/4" FINISHED CEILING SELF-TRIMMING FLANGE 8-3/4"...

  • Page 7: Troubleshooting

    TROUBLESHOOTING SYMPTOM CAUSE SOLUTION Screen will not operate or will not go (a) Incorrect line voltage. (a) Verify 115-125V (or 220-240V). If “down”. insufficient voltage, rewire incoming Motor does not hum. electric line. (b) Blown facility fuse. (b) Replace facility fuse. (c) Tripped facility circuit breaker.
  • Page 8 TROUBLESHOOTING SYMPTOM CAUSE SOLUTION Door does not close. (a) Open door limit switch. (a) Replace switch. (b) No power from screen motor. (b) Replace screen motor. “Down” limit switch incorrect. (a) “Down” limit switch out of (a) See installation instructions. adjustment.
