- Page 1 INSTRUCTION BOOK FOR Boardroom Electrol ®...
-
Page 2: Important Safety Instructions
Important Safety Instructions Installation When using your video equipment, basic safety precautions NOTE: Unit is not to be installed in air handling space. should always be followed, including the following: 1. Install screen by raising unit into position between joists at one end only. - Page 3 Make sure door does not NOTE: Screen has been internally wired at DA-LITE. Wiring bind. Check hinges. Paint or tile cement will interfere with designated “external” is completed by installer conforming to free operation.
- Page 4 Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly adjusted at Da-Lite. Should it be necessary to adjust for more or less drop of picture, proceed in the following manner: NOTE: Use a screw driver or 5/32" allen wrench to make CAUTION! Do not adjust for more drop than what was adjustments.
- Page 5 Screen Adjustment For 220/240V Screens Surface travel is stopped automatically in the fully opened and closed positions by limit switches that are properly adjusted at Da-Lite. Should it be necessary to adjust for more or less drop of picture, proceed in the following manner: NOTE: Use a screw driver or 5/32"...
- Page 6 Boardroom Electrol Intallation ® Select installation method according to ceiling type. Method A Method B Mounting (Suggested) (Suggested) Mounting Bracket 1/4" Bolt Bracket 1/4" Bolt "L" "L" Mounting 7 3/8" Bracket 7 3/8" Mounting Bracket Joist Joist 1 1/2" Drywall 1 1/2"...
-
Page 7: Troubleshooting
Troubleshooting Visit www.da-lite.com/products/tutorials.php to find installation by email at info@da-lite.com or by phone at (800) 622-3737 and troubleshooting tutorials. You will also find a link to or (574) 267-8101 with any troubleshooting questions. Live Chat for interactive support and you can contact us... - Page 8 Troubleshooting Symptom Cause Solution Hinge is bound or has a foreign substance on it Check installation to free door. Clear any foreign substance; which does not allow it to open by gravity.. i.e., paint or plaster from hinge. Door will not open Adjust slat hooks.
- Page 10 OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
