12.0 Appliance Controls

If the controller is displaying German Text undertake the following;
Press the ESC button several times to display the DEFAULT SCREEN.
Press the OK button once, turn the wheel clockwise one click to highlight 'Bedieninheit',
Press the OK button, The screen displays 'Bedieninheit Sprache' 'Deutsch', Press the OK
button to make 'Deutsch' flash, Turn the wheel one click anticlockwise to select
'English'. Press the OK button. The screen indicates 'OPERATOR SECTION, LANGUAGE',
Press the ECS button twice, to return to the main screen.

12.1 Control Panel

12.2 RVS43 143 Cascade Manager

MHG Heating Ltd, Unit 4 Epsom Downs Metro Centre, Waterfield, Tadworth, Surrey, KT20 5LR
P:0845 6448802 F:0845 6448803 E:
© MHG Heating Ltd
1. RVS43 143 Controller Display
2. Upper Module Power Isolator
3. Middle Module Power Isolator
4. Lower Module Power Isolator
5. Module Commissioning Button
6. Appliance Power Isolator
7. System Manometer
