MHG Heating ProCon HT Installation And Operating Manual page 60

swimming pool
Precontroller actual
8930
8931 Precontroller setpoint
Segment flow
8950 temperature actual
Segment flow
8951
temperature setpoint
8952 Segment return temp
Common flow setp
8957
Buffer temp actual
8980
value top (B4)
Buffer storage tank
8981
setpoint
Buffer temp actual
8982
value bottom (B41)
Buffer temp actual
8983
value middle (B42)
Flow temperature
9000
setpoint H1
Flow temperature
9001
setpoint H2
9005 Water pressure H1
9006 Water pressure H2
State multifunctional
9031
relay (QX1)
State multifunctional
9050
relay (QX21 Modul 1)
State multifunctional
9051
relay (QX22 Modul 1)
State multifunctional
9052
relay (QX23 Modul 1)
State multifunctional
9053
relay (QX21 Modul 2)
State multifunctional
9054
relay (QX22 Modul 2)
State multifunctional
9055
relay (QX23 Modul 2)
State 2nd speed
heating circuit pump
Operating mode
changeover heating
circuit 1
State 2nd speed
heating circuit pump
Operating mode
changeover heating
circuit 2
State heating circuit
pump 3/P
Stat 2nd speed
heating circuit pump
