Installation and Operating Manual for the
Alubox Range 50-2200kW
1
MHG Heating Ltd Unit 4 Epsom Dow ns Metro Centre, Waterfield, Tadw orth, Surrey KT20 5LR
Telephone 01737 358000 Fax 08456 448803 Email
info@mhgheating.co.uk
Web w w w .mhgheating.co.uk
010717
