- Page 2 ProCon Smartline ProCon Smartline boiler complies with basic requirements of the following Installer’s-user’s manual ................3 Boiler operating elements ..............68 Directives: Gas directive 90/396/EEC; Yield directive 92/42/EEC; Hydraulic circuit ................69-70 Electromagnetic compatibility directive 89/336/EEC; Low-voltage directive Electric diagrams ................71-75 2006/95/EEC;...
- Page 3 ENGLISH ENGLISH 1 - GENERAL SAFETY DEVICES The boilers produced in our factory are built with care down to the last Do not block or reduce the size of the ventilation openings in the room. component to protect both the user and installer from eventual accidents. Do not leave inflammable containers or substances in the room.
- Page 4 ProCon Smartline to use an insulation transformer with secondary anchored to ground. 3 - HYDRAULIC CONNECTIONS (Fig. 3.1- 3.1a) Gas and/or water pipes may not be used to earth electrical equipment. Position and dimensions of hydraulic connections: Use the supplied power cable to connect the boiler to the mains power C - CH delivery 3/4"...
- Page 5 ENGLISH draught sealed chamber accessories can be used, as they better adapt to Twin ducts (Ø 80 mm) (Fig. 9.3-C) installation characteristics. The twin ducts can be aimed in the most suitable direction for installation For fume extraction and burning air restoration in boiler, use original pipes or needs.
- Page 6 ProCon Smartline 10 - TECHNICAL DATA 15 H 15 HS 25 HS Nominal thermal flow rate 15,00 25,00 15,00 kcal/h 12.900 12.900 21.500 Nominal thermal power (80°/60°) 14,5 24,3 14,5 kcal/h 12.500 12.500 20.898 Nominal thermal power (50°/30°) 15,70 26,30 15,70 kcal/h 13.532...
- Page 7 ENGLISH 30 S 30,00 Nominal thermal flow rate 25.800 kcal/h 29,0 Nominal thermal power (80°/60°) 24.949 kcal/h 31,4 Nominal thermal power (50°/30°) 27.038 kcal/h 7,00 Reduced thermal flow rate 6.020 kcal/h Reduced thermal power (80°/60°) 5.857 kcal/h Reduced thermal power (50°/30°) 6.339 kcal/h 33,00...
- Page 8 ProCon Smartline 11 - MULTIGAS TABLE Lower Wobbe index (15°C-1013 mbar) MJ/m 45,67 70,69 Lower heat value MJ/m 34,02 Supply nominal pressure mbar (mm H 20 (203,9) 37 (377,3) Supply minimum pressure mbar (mm H 10 (102,0) ProCon Smartline 15 H - 15 HS Number of main burner nozzles n°...
- Page 9 ENGLISH display shows the value being selected. About 4 seconds after the selection 12 - START-UP AND OPERATION has been made, the modification is memorised and the display returns to the ProCon Smartline wall-mounted condensation boiler designed for the delivery temperature. production of heating and domestic hot water (for H-HS models if connected to an external water tank).
- Page 10 ProCon Smartline • Move the function selector to the desired position. In case of frequent pressure drops, call in the Technical Service Centre. Code Description of alarm Status AL10 Ignition attempts finished (no flame/condensate present) Block Only for S.: AL60 fault AL20 Limit thermostat fault Block...
- Page 11 ENGLISH 12.4 - Boiler configuration Though delivery temperature is automatically calculated by the boiler, the user may manually override it. The electronic board contains a series of jumpers (JP4) that can be used By modifying HEATING on the user interface (C, fig. 13.2), the HEATING to configure the boiler;...
- Page 12 ProCon Smartline 18 - CHANNEL DIGITAL CLOCK • To exit the flue cleaner function, turn the control knob 6 • Remove the fumes analysis probe and put back the plug. SETTING THE DAY & TIME Remount the knobs on the panel. The “combustion analysis” function ●...
- Page 13 ENGLISH Press P to confirm and store the new value ● Use the same (above) sequence for the subsequent ON/OFF settings and ● subsequent days. Once the programming of C1 (Heating) channel has been completed, the ● programmer sequence will automatically move on to C2 (Hot water). NOTE If no buttons are pressed within a 10-second period, the programmer will exit the programming mode and revert to the normal display.
- Page 14 ProCon Smartline ProCon Smartline S ProCon Smartline HS ProCon Smartline H [PL] - Elementy obsługi kotła (S-HS-H) [PL] - Elementy obsługi kotła (S-HS-H) [PL] - Elementy obsługi kotła (S-HS-H) [PL] - Elementy obsługi kotła (S-HS-H) [PL] - Elementy obsługi kotła (S-HS-H) [EN] - Boiler operating elements (S-HS-H) [DK] - Kedlens betjeningselementer (S-HS-H) 1 - Zawór gazu...
- Page 15 ProCon Smartline ECOHEAT Gas ProKondens S ProCon Smartline S [PL] - Obwód hydrauliczny [PL] - Obwód hydrauliczny [PL] - Obwód hydrauliczny [PL] - Obwód hydrauliczny [PL] - Obwód hydrauliczny [EN] - Hydraulic circuit (S) [DK] – Hydraulisk kredsløb (S) A - Powrót ogrzewania A - Heating return A - Opvarmning retur B - Wlot gorącej domowej wody...
- Page 16 ProCon Smartline ProCon Smartline H ProCon Smartline HS [PL] - Obwód hydrauliczny (H-HS) [PL] - Obwód hydrauliczny (H-HS) [PL] - Obwód hydrauliczny (H-HS) [PL] - Obwód hydrauliczny (H-HS) [PL] - Obwód hydrauliczny (H-HS) [EN] - Hydraulic circuit (H-HS) [DK] – Hydraulisk kredsløb (H-HS) A - Wlot zimnej wody A - Cold water inlet A - Koldvandsindtag...
- Page 17 ProCon Smartline ProCon Smartline S...
- Page 18 ProCon Smartline ProCon Smartline HS...
- Page 19 ProCon Smartline ProCon Smartline H [EN] - Multi-wire diagram (S - HS - H) “L-N” polarisation is recommended Bl=Blue / Br=Brown / Sw=Black / Rt=Red / Ws=White / Vt=Violet / Gb=Yellow / Or=Orange / Gr=Gris / Verde=Gn / Rs=Pink GA=Gas valve /F=Fuse Hz.
- Page 20 ProCon Smartline R10 – Regulator minimalnej prędkości wentylatora [ES] - Esquema eléctrico multihilo (S- HS-H) F1-F2 – Sikring 3.15A T (forsinket) R14 – Regulator prędkości powolnego rozruchu La polarización L-N è aconsejada DFS – Brugsvandets flow-afbryder (S) R19 – Regulator maksymalnej prędkości wentylatora Bl=Azul /Br=Marrón /Sw=Negro /Rt=Rojo / Ws=Blanco / –...
- Page 21 ProCon Smartline S - HS -t° 230 V F = SI 3.15AF -t° (EXTERN) [DK] – Tilslutning af omgivelsestermostat og/eller PL] - P PL] - P PL] - Podłącz odłącz odłącz odłączenie ter enie ter enie ter enie termosta mosta mosta mostatu i/lub z tu i/lub z...
- Page 22 ProCon Smartline 15 HS - H 25 HS 30 S [EN] - Circulator residual head [RO] - Caracteristica de debit a pompei [RO] - Caracteristica de debit a pompei [RO] - Caracteristica de debit a pompei [RO] - Caracteristica de debit a pompei [RO] - Caracteristica de debit a pompei A - Residual head (x 100 mbar) A - Cap rezidual (x 100 mbar)
- Page 23 ProCon Smartline - 3.1 - [EN] Dimensions in mm 30 S 452,5 205 [ES] Medidas en mm 25 HS 452,5 205 [PL] Wymiary w mm 15 HS-H 400 [RO] Dimensiuni in mm [DK] Dimensioner i mm [FR] Dimension en mm [EN] H- Water-gas [ES] H - Agua-gas [PL] H - Woda-gaz...
- Page 24 ProCon Smartline - 8.2a - - 8.1 - - 8.2 - - 8.3 - - 8.4 - - 8.5 - - 9.1 - - 9.2 - B23P B53P 111,25 111,25 [EN] A - Rear outlet / B - Max 50 cm [ES] A - Salida trasera / B - Màx 50 cm [PL] A - Tylny wylot / B - Maks.
- Page 25 ProCon Smartline - 9.3 - [EN] A - Fumes duct for intake in environments / B - Concentric duct for fumes outlet/air intake / C - Twin duct for fumes outlet/air intake / D - Adaptor Ø 60-80 [ES] A - Conducto humos aspiración en ambientes / B - Conducto concéntrico para evacuación de humos/extracción aire / C - Conducto desdoblados para evacuación de humos/extracción aire / D - Adaptador Ø...
- Page 26 ProCon Smartline - 13.2 - - 13.1 - display - 13.4 - - 13.3 - Curva climatica GIORNO Curva climatica NOTTE + 5 C - 5 C Temperatura Esterna [EN] [PL] [PL] [PL] [PL] [PL] [DK] A - Thermoregulation curves A - Termoreguleringskurver A - Krzywe termoregulacji B - Climate curve correction...
