Control Parameter Defaults; Rvs43 143 Cascade Manager - MHG Heating ProCon HT Installation And Operating Manual

© MHG Heating Ltd
14.0 Control Parameter Default Settings.
14.1 RVS43 143 Cascade Manager Settings.
Boiler Mounted Unit AVS37 Room Unit QAA75
If the controller is displaying German Text undertake the following;
Press the ESC button several times to display the DEFAULT SCREEN.
Press the OK button once, turn the wheel clockwise one click to highlight 'Bedieninheit',
Press the OK button, The screen displays 'Bedieninheit Sprache' 'Deutsch', Press the OK
button to make 'Deutsch' flash, Turn the wheel one click anticlockwise to select
'English'. Press the OK button. The screen indicates 'OPERATOR SECTION, LANGUAGE',
Press the ECS button twice, to return to the main screen.
