12.5 Accessing Module Parameters

1. Press the display mode button (10) to choose display level «P» (keep button
depressed).
2. Press the display mode button (10) to choose the required parameter (press button
briefly).
3. Adjust the value:
Changing parameters: (only P0...P6)
Only parameters P0...P6 can be changed.
To do this, wait until the value of the parameter flashes on the display (3).
Proceed as follows:
P ❍ (+) or (Enter)
❍ (-)
P ❍ (+) or (Enter)
If the displayed value does not require amending or the altered setting is not required
do not press any buttons on the controller for a period greater than 12 seconds.
As a confirmation, the display (3) shows P0...P6 in consecutive order and the newly
adjusted value.
The new value will only be adopted after storage.
Reviewing the Parameter Values
To query the different parameter values, proceed as follows:
Choosing the display mode
Choose the display mode by pressing button (10) for more than 3 seconds (display (3):
A...). Keep button (10) depressed to reach the different display levels b, C, d, P
and back to A.
Release the button when the required display level is reached (A, b, C, d, P).
Choosing and displaying individual values or parameters
To change between the different values or parameters (0... max. 7) of the different
display
levels (A, b, C, d, P), press button (10) briefly.
The current value appears about 2 seconds after choosing the relevant parameter.
MHG Heating Ltd, Unit 4 Epsom Downs Metro Centre, Waterfield, Tadworth, Surrey, KT20 5LR
P:0845 6448802 F:0845 6448803 E:
© MHG Heating Ltd
Increase value (+): Press display mode button (10) briefly several
times (< 1 second)
Decrease value (-): Press chimney sweep button (11) briefly
several times (< 3 seconds)
Save value (Enter): Press display mode button (10) for at least 3
seconds
