MODEL
CL 10SA
POWER TOOLS
C
TECHNICAL DATA
STUD CUTTER
AND
CL 10SA
SERVICE MANUAL
LIST No. 0789
Jan. 2001
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT

Advertisement

   Also See for Hitachi CL 10SA

   Summary of Contents for Hitachi CL 10SA

  • Page 1

    MODEL CL 10SA POWER TOOLS TECHNICAL DATA STUD CUTTER CL 10SA SERVICE MANUAL LIST No. 0789 Jan. 2001 SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT...

  • Page 2

    LIST NO. 0789 ELECTRIC TOOL PARTS LIST STUD CUTTER 2001 • • Model CL 10SA (E1)

  • Page 3

    PARTS CL 10SA ITEM CODE NO. DESCRIPTION REMARKS USED CAUTION PLATE (E) 319-411 HOUSING (A).(B) SET 319-402 PUSHING BUTTON (A) 319-403 SPRING (A) 981-373 TUBE (D) FOR CORD 319-412 SWITCH 992-635 EARTH TERMINAL 994-273 NOISE SUPPRESSOR 953-327 CORD ARMOR D8.8 938-051 CORD ARMOR D10.1...

  • Page 4

    PARTS CL 10SA ITEM CODE NO. DESCRIPTION REMARKS USED 307-606 MACHINE SCREW (W/WASHERS) M4X20 (BLACK) 319-838 COVER 319-396 BOLT (A) 987-203 SEAL LOCK SCREW (W/SP. WASHER) M4X12 319-398 RETURN PLATE 319-397 BRACKET (A) 931-875 TAPPING SCREW D5X35 319-395 BRACKET (B) 949-574 LOCK NUT M12 (10 PCS.)

  • Page 5: Standard Accessories

    CL 10SA STANDARD ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 308-569 TRIMMER M8 OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 308-563 CUTTER ASS’Y M6 (1 PAIR) INCLUD.602 309-181 SPACER M6 (10 PCS.) 308-565 CUTTER ASS’Y M10 (1 PAIR) INCLUD.604 308-780 SPACER M10 (10 PCS.)
