Outer Rack Rails

007-5759-001
1
2
3
4
5
6
Figure 2-1 Separating and Installing the Rack Rails
Outer rails attach to the rack and hold the chassis in place. The outer rails for the chassis extend
between 30 inches and 33 inches.
Rail Assembly
Extending the Rails
Quick-
Release Tab
Separating the
Inner Rail Extension
7
Install the System into a Rack
13
