T W O - W A Y
CS-495iTW-FM
Depending on your usage of the transmitter, the battery can last anywhere between 3 to 6 months. When the
battery is low, the transmitter will produce two beeps in a repetitive cycle. At that point you should replace
your battery with a new one. That is why we recommend that you keep a spare battery somewhere handy
such as the glove compartment.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user's authority to operate the equipment.
DOC: 1.00
- 2W-FM-LCD-6020-A-M -
6 - B U T T O N
T R A N S M I S S I O N
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle
is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled
or put into valet mode before servicing.
A note concerning the battery inside the transmitter:
L C D
A U T O M A T I C / M A N U A L
R E M O T E
S T A R T E R
WARNING
- September 8, 2007 -
- MO -
Assembled in Canada
Advertisement
Table of Contents
Related Manuals for Autostart CS-495iTW-FM
Summary of Contents for Autostart CS-495iTW-FM
- Page 1 T R A N S M I S S I O N R E M O T E S T A R T E R CS-495iTW-FM User Guide WARNING It is the responsibility of the vehicle operator to ensure their vehicle is parked in a safe and responsible manner.
-
Page 2: Table Of Contents
Table of Contents Introduction ............2 Priority Door Access.......... 9 Vehicle Presets............3 Ignition-Controlled Door Locks......10 Heater & Heated Seat ........3 Ignition Re-lock..........10 Windshield Wipers & Radio & Headlights..3 Secure Lock ............ 10 Using the Remote Control........3 Remote Trunk Release ........ -
Page 3: Vehicle Presets
Vehicle Presets Heater & Heated Seat When leaving the vehicle it is recommended to preset the accessory controls in preparation for the next remote start. Settings for the blower motor (fan), front and rear, as well as heated seats (if equipped) should not be left on . -
Page 4: Basic Vehicle Operations
For certain vehicles: • Pressing and holding the button for more than 3 seconds will lock all doors and will send a constant pulse as long as the button is held down (maximum of 15 seconds). This constant pulse can be configured to activate certain functionalities such as rolling up the windows – Please refer to your installer to see if your vehicle is compatible with this option. -
Page 5: Timing Countdown Adjustment
Press and hold the button once more until a beep is heard, ........ Release the button displayed ....you can now adjust the hour At that point, press and hold the button until 2 (current time). beeps are heard. a. Press the button to increase the value or to activate or deactivate a function or to toggle through the melodies. -
Page 6: Remote-Starting Your Vehicle
Remote-Starting Your Vehicle If your vehicle has an automatic transmission, simply press the button to remote start START/STOP or stop your vehicle. Skip the next steps on to “Remote-starting”. Warning: If you vehicle has an automatic transmission and the parking lights flash 15 times after pressing the button, the parking brake is connected to ground. -
Page 7: Driving Off
Driving Off With the vehicle running under remote control, press the button to disarm and unlock the doors. Enter the vehicle and do the following: • Turn the ignition key to the position. (Do not turn the key to the IGNITION ON (RUN) CRANK position while the engine is running. -
Page 8: Remote Valet Mode
• The parking lights will flash three times to indicate that the vehicle is now in valet mode. The L.E.D. will come on solid. — The icon will appear on your LCD remote. To take the system o u t o f valet mode: •... -
Page 9: How To Enter Cold Weather Mode
24 hours. The vehicle must be set in ready mode (manual transmission) before the cold weather mode can be activated. To enter Cold Weather Mode: • Press and release the button until you hear a beep. Release the button, will appear, then press and hold the button for 3 seconds until the parking lights flash three times. -
Page 10: Ignition-Controlled Door Locks
Ignition-Controlled Door Locks This is an added security feature. If your remote starter was installed with the ignition-controlled door locks option, the doors will automatically be locked as soon as the ignition key is turned to the position while the brakes are pressed. When the key is turned to the position, IGNITION ON (RUN) the doors will automatically be unlocked. -
Page 11: Safe Start
No Stop Confirmation Was Received: If after remote stopping the vehicle no confirmation was received i.e. the display did not return to its basic state simply press the button, this will refresh the display. If the engine was stopped, the smoke icon and the hourglass icon will disappear and the time will be displayed. Pressing the button will also lock all doors (the lock icon will appear). -
Page 12: Turbo Mode
To take the system i n t o home valet mode: • Press the button. • Within 3 seconds, press the and buttons simultaneously until the parking lights go out To take the system o u t o f home valet mode: •... -
Page 13: Engine Run Time
button is enabled (this will by-pass Turbo Mode). TO SET THE VEHICLE INTO IDLE MODE Engine Run Time If you have a gas engine, your remote starter can be programmed to run the engine for 3, 15, or 25 minutes (15 minutes by default). If you have a diesel engine, the remote starter can be programmed to run the engine for 8, 20, or 30 minutes (20 minutes default). -
Page 14: Multi-Car Operation
Multi-car Operation This option allows the owner of two vehicles, both equipped with the same remote starter model, to control both systems with a single remote control. To control the second vehicle: • Press : ..............LOCK • Press :..............UNLOCK •... - Page 15 Multi-Car Operation (press the button 2X) ....... car lock ....... : 2nd car unlock ....... : car start/stop ....... car trunk Customized Features (press the button 3X) (May not be compatible with some vehicles) Your installer can add customized features such as turning on the radio, opening sliding doors, etc.......
-
Page 16: Troubleshooting Poor Transmitting Range
Option 3: Level 1 (requires pressing the button 1X) Customized features Level 2 (requires pressing the button 2X) Multi car operation Level 3 (requires pressing the button 3X) Basic features Option 4: Level 1 (requires pressing the button 1X) Basic features Level 2 (requires pressing the button 2X) Customized features... -
Page 17: Diagnostics - Parking Light Flash Table
Diagnostics – Parking Light Flash Table Flashes Description • • Doors locked, starter kill armed. Start signal received by the module. • • Run time has expired. Cold weather mode cancelled. • • button pressed. Enabled LED TRUNK • Remote start attempt cancelled by •...
