A U T O M A T I C T R A N S M I S S I O N M U L T I - C H A N N E L R E M O T E S T A R T E R S Y S T E M
Table of Contents................................................................1
Introduction .........................................................................2
Included in the Kit ...........................................................2
Before You Get Started..................................................2
Installation Points to Remember.....................................3
PS-2925 Features List....................................................3
Plug-ins...........................................................................3
Harness Description............................................................4
Wiring Diagram ...................................................................6
Transmitter Functions .........................................................7
Programming a Transmitter ................................................7
Multi-Speed Tach Learning.................................................7
The Programming Assistance Button .................................8
Valet Operation...................................................................8
Programming Options.........................................................8
Programmable Features .....................................................9
Ignition-controlled Door Locks........................................9
Secure Lock....................................................................9
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of the product, be
that either damage to the vehicle itself or to the Unit. This Unit must be installed by a certified technician using all safety devices
supplied. Only registered technicians will be eligible to use the Autostart technical support telephone service.
Please review the Installation Guide carefully before beginning any work.
Warning
This unit is designed for vehicles with an
does not start when the gear select lever is in the "Drive" position. If it starts in gear, install a manual-transmission car starter
instead.
H.1.20.S.2.00
PS-2925
Installation Guide
Table of Contents
automatic
Transmission only. Before installing the Unit, test that the vehicle
β.2.05 - Gf Fb Gp CA
Rev.1.06- August 5, 2002
Passive or Active Arming ............................................... 9
Lock Pulse Duration..................................................... 10
Engine Run Time ......................................................... 10
Idle Mode ..................................................................... 10
Other Features of the Module .......................................... 11
Ground Out When Running ......................................... 11
Starter Kill Circuit (Installation)..................................... 11
2
Ignition / Accessories / Crank Relay Output........... 11
External Trigger ........................................................... 11
The Trunk Output......................................................... 12
Cold Weather Mode ..................................................... 12
Multi-car Operation ...................................................... 12
Events Logging and Playback...................................... 13
Resetting the Module ....................................................... 13
Diagnostics - Parking Lights Flash Rate .......................... 13
Testing.............................................................................. 14
Troubleshooting Poor Transmitting Range....................... 13
Closing Up........................................................................ 14
Manufactured in Canada by Autostart
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Autostart PS-2925
Summary of Contents for Autostart PS-2925
-
Page 1: Table Of Contents
Unit. This Unit must be installed by a certified technician using all safety devices supplied. Only registered technicians will be eligible to use the Autostart technical support telephone service. Please review the Installation Guide carefully before beginning any work. -
Page 2: Introduction
The Unit can be easily integrated into just about any of today’s most complex vehicles. We hope that you too, after installing this system, will agree that the new PS-2925 is a major breakthrough in Remote Starter systems and vehicle convenience technology. -
Page 3: Installation Points To Remember
** The INV-200 is optional Plug-ins The PS-2925 system has been designed with simple plug-ins that will speed up the installation. The system offers a plug -in L.E.D., a plug-in Valet Button, and a plug-in powered Antenna. PS-2925 Installation Guide... -
Page 4: Harness Description
Harness Description When connecting an Autostart Module, it is important to make sure that the connector with the Ground wire is connected first, before making the 12-volt connections. Should the Unit be powered up before being grounded, there could be serious damage to internal components of the Unit. - Page 5 Note: the Module will nevertheless proceed cranking the Engine if the Glow-plug Light is still on after the 18-sec. delay (25 sec. when run time is set to 30 min.). See the Diesel Glow-plug Indicator Light section on p. 10 for more details.. PS-2925 Installation Guide P. 5...
-
Page 6: Wiring Diagram
Wiring Diagram P. 6 Installation Guide PS-2925... -
Page 7: Transmitter Functions
Programming a Transmitter Once the wiring of the Module is complete, the Transmitter must be code-learnt. The PS-2925 Module can learn up to 4 different Transmitters. If a fifth Transmitter is learnt, the code of the first Transmitter in memory will be lost. To erase all Transmitters from memory, you must reset the Module. -
Page 8: The Programming Assistance Button
The Programming Assistance Button (A.k.a. the Hood Switch Interrupt.) Mounted on the PS-2925 Module, this button can be used from within the vehicle in- stead of the Hood Pin-switch in the Engine compartment: when the Hood is opened, pressing the Hood Switch Inter- rupt button will be equivalent to pressing the Hood Pin-switch –... -
Page 9: Programmable Features
The Parking Lights will flash once. (If the Door Locks option was installed, this will also lock the Doors). In Passive Mode, the system will automatically arm itself 1 or 3 minutes after the Engine is shut down. PS-2925 Installation Guide P. 9... -
Page 10: Lock Pulse Duration
(18 sec., recommended). • Keeping the Glow-plug input wire of the Module unconnected will hold the ignition for the minimum waiting time (3 sec., not recommended in very cold environments). P. 10 Installation Guide PS-2925... -
Page 11: Other Features Of The Module
30 (this could result in serious damage to the vehicle). Ignition / Accessories / Crank Output The PS-2925 comes equipped with a high-current programmable 5 relay which can be used to power a 2 Ignition, Accessory, or Crank Wire. -
Page 12: The Trunk Output
Place the vehicle in Valet Mode. Multi-car Operation PS-2925 systems allow for Multi-car operation. This allows the owner of two Autostart-equipped vehicles to control both systems with one Transmitter. (Both vehicles must be equipped with an PS-2925.) The Transmitter of the primary vehicle can control the Starter Kill system, the Door Locks, the remote car Starter and Trunk operation of the second vehicle. -
Page 13: Events Logging And Playback
Parking Lights still give 1-long flash. Resetting the Module The PS-2925 system is equipped with a reset function that allows the installer to erase all Transmitter codes and return all Programming Options to their factory default values. To reset the module: Ensure the Ignition is , that Valet Mode is disabled and that the Hood is up. -
Page 14: Testing
Doing this will save time and money. Always make all your connections before plugging in the module and be sure to test all functions properly before closing up the installation. P. 14 Installation Guide PS-2925...
