Autostart AS-1200 Installation Manual

Automatic transmission remote engine starter systems

Advertisement

AS-1200/1202/1203/1204 SH
AS-1200/1202/1203/1204 SH
AS-1200/1202/1203/1204 SH
AS-1200/1202/1203/1204 SH
Automatic transmission remote engine
Automatic transmission remote engine
Automatic transmission remote engine
Automatic transmission remote engine
Table on contents.................................1
What's included....................................2
Notice..................................................2
Install points to remember.....................2
Features..............................................2
Options...............................................2
Programmable options..........................2
Electronic Valet Mode...........................2
Transmitter code learning......................3
Multi car operation................................3
Tach Adjustment..................................3
NOTICE:
DUE TO THE POTENTIAL FOR DAMAGE TO THE VEHICLE, THE MANUFACTURER IS NOT
RESPONSIBLE FOR ANY ELECTRICAL OR MRCHANICAL DAMAGE TO THE VEHICLE OR TO
THE UNIT THAT HAS CAUSED VEHICLE DAMAGE DUE TO IMPROPER INSTALLATION OF THE
PRODUCT.
THIS UNIT MUST BE INSTALLED BY AN AUTHORIZED AUTOSTART TRAINED TECHNICIAN
USING ALL SAFETY DEVICES SUPPLIED.
Please review the installation guide carefully before any work begins.
WARNING
THIS UNIT IS FOR AUTOMATIC TRANSMISSION ONLY, BEFORE INSTALLING THE UNIT
TEST THAT THE VEHICLE WILL NOT START IF THE GEAR SELECT LEVER IS IN A
DRIVE POSITION. IF IT STARTS IN GEAR, INSTALL A MANUAL TRANSMISSION CAR
STARTER. (AS-1260M)
Rev:1.04 - 8/16/99 Manufactured in Canada by AUTOSTART
AUTOSTART
AUTOSTART
AUTOSTART
AUTOSTART
starter systems.
starter systems.
starter systems.
starter systems.
INSTALLATION GUIDE

Table of Contents

Door lock toggle mode.............................4
1
Manual Tach adjustment.........................3
Custom Programming Options.................4
Vaccum mode........................................5
Tach watch Lockout...............................5
Idle Mode..............................................5
Diesel Engine.........................................5
Module Reset.........................................5
Harness Description...............................6
AS-1202 Wiring Schematic.......................8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-1200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Autostart AS-1200

  • Page 1: Table Of Contents

    THE UNIT THAT HAS CAUSED VEHICLE DAMAGE DUE TO IMPROPER INSTALLATION OF THE PRODUCT. THIS UNIT MUST BE INSTALLED BY AN AUTHORIZED AUTOSTART TRAINED TECHNICIAN USING ALL SAFETY DEVICES SUPPLIED. Please review the installation guide carefully before any work begins.
  • Page 2: What's Included

    WHAT’S INCLUDED FEATURES Please review the installation guide before Dual 12 volt power lines. beginning the installation, particularly the 12 volt parking light output. wiring diagram and the list of programming Multi channel transmitter. (AS-1203/04 options. Only) Prior to installation please be sure that all Multi car operation.
  • Page 3: Transmitter Code Learning

    2. Release pinswitch (parking lights should TRANSMITTER CODE LEARNING come on) 3. With parking lights on, immediately push All Autostart transmitters do not come pre- and release pinswitch again. programmed. They must be “CODE 4. Parking lights will stay on for up to 20 LEARNED”...
  • Page 4: Custom Programming Options

    4 seconds) *DOOR LOCK TOGGLE MODE MODE 2 * INDICATES DEFAULT SETTING Autostart has a built-in starter kill feature and even if the starter kill is not installed, the logic FUNCTION 1 for it still dominates the operation of the system.
  • Page 5: Vaccum Mode

    FUNCTION 2 If module is still in Tach Watch Lockout move tach wire to a better tach source and OPTION 1 2 start attempts perform an Automatic Tach Setting. Then OPTION 2* 3 start attempts repeat steps 1 to 5. OPTION 3 4 start attempts IDLE MODE...
  • Page 6: Harness Description

    HARNESS DESCRIPTION HARNESS DESCRIPTION HARNESS DESCRIPTION HARNESS DESCRIPTION 7-PIN HARNESS PIN # COLOR POLARITY DESCRIPTION (connect to...) BLACK Chassis Ground Ground to vehicles chassis. VIOLET Tach Input (Coil -) Connect to vehicle's tach wire (coil -) GRAY Hood Switch Hood switch - grounded when hood open EMPTY Glow plug input(+) Connect to wait to start light on diesel vehicles.
