- Page 4 WIRING SCHEMATIC For Automatic Transmissions REAR VIEW OF MODULE Leave Orange wire unconnected. RS-232 Port INV-200 Connector Jumpers for second outputs Pager port (Starter, Ignition, Accessories) Loop Bypass/GPS port Bypass/GPS port RS-232 port Accessories 2 Jumper Pager port Ignition 2 Jumper INV-200 CONNECTOR LOOP Starter 2 Jumper...
