LJD Digital Security Colossus Pro User Manual page 39

Step 3
Follow these steps to perform smart search:
1. Click [Smart Search] button to enter smart search mode.
2. Choose to search either in full screen or a defined area, here we click [Area] button
to search in a defined area.
3. Drag the red rectangular, and zoom it to select a area you want to detect motion
event.
4. Configure sensitivities, such as color, motion speed, area and delay parameters, then
click [search] button to start search. A search progress bar will be displayed in the
video screen.
5. When finished searching, result files or clips will be listed in the down part screen.
6. Double click these clips to playback this video.
7. Click [Smart Search] again to exit smart search mode.
Step 5
Figure 3-13 Smart Search interface
Page 39 of 66
Step 1
Step 2
Step 4
