FB-130N Series
Camera
Hardware System CPU: 500 MHz
Flash: 16M
RAM: 128M DDR
Image Sensor Sensor Type : 1/3" Sony CMOS Sensor
Sensor Resolution : 1280 x 1024 pixel
Minimum Illumination : 0.1 Lux (F1.3,B/W)
Day & Night Mechanical ICR , Triggered by Light sensor,
Support Scheduling, Digital Input
Audio
Audio Streaming 2-way audio support
Audio G.711, AMR (8 kHz, Mono, PCM)
Compression
Audio External microphone or line input (Unbalanced,
Input/ Output 1.4 Vp-p, 1 Vrms)/Line Output
Video
Video Image H.264 / MPEG4 / MJPEG
Compression
Video Setting Auto Exposure Control:
Sport, Normal, Night Vision, User Defined
Auto Gain Control: 1X~5X
Shutter Speed: 1/32000~1s
S/N Ratio Above 50dB
Image Resolution 1.3M
- 1280x1024@25fps
1M
-1280x720@30fps
FB-130N Series
Wireless (11a/b/g/n dual band WiFi)
Auto Iris Support
WPS Button
Work Best With
Camera Accessories Options
M13VG288IR
2.2x Manual zoom/focus, DC iris
YV2.1x2.8SR4A-SA2L
2.1x Vari-focal Lens with DC Iris
CI-803C
Camera Bracket
Copyright 2012 Brickcom Corporation. All rights reserved. All other company
names and products are trademarks or registered trademarks of their respective
companies. We reserve the right to introduce modifications without notice.
0.5 Lux(F1.3,Color)
FB-130Np
-

-
General
Communication Ethernet : one 10/100Mbps RJ-45
IEEE 802.11a/b/g/n compliance
Supported Protocols : TCP/IP, UDP, ICMP,
DHCP, NTP, DNS,
DDNS, SMTP, FTP, HTTP, Samba, PPPoE,
UPnP, RTP, RTSP,
RTCP, Wireless 802.11 a/b/g/n
Power input AC 24V
DC 12V / 1A (Power Supply)
PoE:802.3af Compliant
LEDs FB-130N
Status/Ethernet(Power/Link)
WFB-130N
Status/WPS/Ethernet(Power/Link)
Power
5 watts
consumption
Environment
Operating Temperature : 0°C ~ 50°C (32°F
~122°F)
Operating Humidity : 10% ~ 80%
Dimension 124(L)*60 (W)*65(H) mm
Weight FB-130N
Net: 380g (Without Lens)/0.83lb
Gross : 893G/1.97lb
WFB-130N
Net: 385g (Without Lens)/0.85lb
Gross: 903G/2.00lb
Certification
FCC, CE
Warranty
Limited 2-year warranty
Network Equipment Options
DWRT-600N
Dual Band Wireless Router
PS-7242IL-AF
24-port 10/ 100M PoE Web Smart Ethernet
Switch
(WFB-130N)
(WFB-130N)
WFB-130Np



