Section 3 Read Status; Point Select Screen - Johnson Controls IFC-3030 Operation Manual

Point Select Screen

This section contains instructions and screen illustrations for Read Status functions and menus
using the IFC-3030 display.
Read Status allows viewing of detailed device status information without entering a password or
halting full fire protection. Information can be viewed while a fire alarm or trouble condition exists.
Read Status screens are refreshed periodically with up-to-date information.
Read Status can be reached from the Main Menu screen, which is accessible from the System
Normal screen and from most other screens by pressing the BACK soft key until it displays. (Refer
to Figure 1.5 for an illustration of the Main Menu screen.)
Press the READ STATUS soft key on the Main Menu screen to bring up the following screen.
3.1 Point Select Screen
When READ STATUS is pressed at the Main Menu, the following screen appears.
Soft Keys
POINT SELECT - Pressing this soft key scrolls through the various device types. The types and
their address formats are illustrated in Table 3.1.
Type
Detector
Module
Panel Circuit
General Zone
Logic Zone
Release Zone
Special
Function Zone
Trouble Zone
Annunciator
Enter an address to view its attributes (the cursor will be in the underlined section).
IFC-3030 Operations Manual — PN 52026:C 08/05/2005

Section 3 Read Status

L A K E V I E W G E N E R A L H O S P I T A L
S Y S T E M N O R M A L
1 0 : 2 2 : 3 4 A F R I S E P 2 4 , 2 0 0 4
P O I N T S E L E C T
P O I N T S E L E C T :
L y y D z z z ( D E T E C T O R )
N E X T P O I N T
P R E V I O U S P O I N T
Figure 3.1 Point Select Screen for Read Status
Address
Format
LyyDzzz L=Loop, yy=Loop number (1-10)
D=Detector, zzz=Detector address (1-159)
LyyMzzz L=Loop, yy=Loop number (1-10)
M=Module, zzz=Module address (1-159)
Pyy.z P=Panel circuit, yy=Panel Module Number (1-12), z=panel module point (1-8)
Zyyy Z=Zone, yyy=Zone number (0-999)
ZLyyyy ZL=Logic Zone, yyyy=Logic Zone number(1-1000)
Ryy R=Releasing Zone, yy=Releasing Zone number (00-09)
ZFxx ZF=Special Function Zone, x=Special Function Zone number (00, 01, 02, 03,
04, 05, 09)
ZTyyy ZT=Trouble Zone, yyy=Trouble Zone number (1-100)
AxxPyy A=Annunciator, xx=ACS address (1-32), P=Point, yy=Point address (1-96)
Table 3.1 Address Formats
Read Status
A C C E P T
B A C K
41
