Please read and save these instructions. This manual contains important instructions for ONEAC models:
• SE041XAT
• SE061XAT
• SE081XAT
• SE101XAT
• SEBP610-2
Follow these instructions during installation and maintenance of the UPS and batteries.
If you have a problem with the UPS, please refer to this manual before contacting Technical Services. The
Troubleshooting section on page 31 addresses most UPS-related issues.
Chloride North America
27944 North Bradley Road
Libertyville, IL 60048-9700
USA
Telephone: (847) 816-6000
Toll Free: (800) 327-8801
Facsimile: (847) 680-5124
ONEAC, Sinergy, and MopUPS are registered trademarks of Chloride Group plc. All other trademarks, product and corporate names are the property of their respective owners.
Battery Test ................................27 Maintenance ..................................27 Storage ..................................27 Battery Maintenance and Disposal/Recycling of Batteries ..................27 Interfaces ..................................28 Serial Interface COM 3 .............................29 Interface Slot COM ..............................29 Optional Isolated Contacts Card ..........................30 Troubleshooting ................................31 ONEAC Sinergy SE II Series UPS User Manual...
Page 3
Appendix A: Features and Specifications ........................32 Features .................................. 32 Specifications ................................33 Appendix B: Paralleling UPS Devices ..........................35 Installing a Parallel System ............................38 ONEAC Sinergy SE II Series UPS User Manual...
Introduction Introduction Thank you for selecting this uninterruptible power supply (UPS). ONEAC’s Sinergy SE II Series UPS offers the most reliable protection from the harmful effects of electrical line disturbances for your computing and communications equipment. ONEAC’s ISO 9001 certification represents our commitment to building world-class products.
WARNING: Indicates instructions, which if not observed, present risk of electric shock, may endanger your life, your health, reliability of your UPS or the security of your data. ONEAC Sinergy SE II Series UPS User Manual...
• The Remote Power Off (RPO/ESD) contacts are located on the rear of the unit (Figure 9). When this connection is open, the logic circuit will immediately shut down the UPS output. ONEAC Sinergy SE II Series UPS User Manual...
• Hand operated pallet jack • Scissors • Screwdriver ATTENTION: The equipment must be kept upright at all times and handled with care; damage may be caused if dropped or subjected to severe impact. ONEAC Sinergy SE II Series UPS User Manual...
Page 8
Setup Fig. 1: Step 1: Remove Strapping Fig. 2: Step 2: Lift Carton Cover ONEAC Sinergy SE II Series UPS User Manual...
Page 9
floor where the UPS will be positioned. ATTENTION: To ease movement over short distances the UPS is fitted with wheels. Before removing the UPS from the pallet, raise the leveling feet on the unit. ONEAC Sinergy SE II Series UPS User Manual...
Electrical maintenance and servicing, which may involve removal of the panels (see Figure 5) requires access to all four sides of the UPS. Provide the necessary space or use a flexible wiring system to allow movement of the UPS. Fig. 5: Accessibility - Removable Panels ONEAC Sinergy SE II Series UPS User Manual...
Front and Sides Air outlet Rear NOTE: IEC/EN 62040-1 specifications do not include operation over 1000 meters. Contact ONEAC Technical Services for other applications. ATTENTION: Some particularly sensitive electronic equipment may be susceptible to interference; in order to prevent this it is suggested that input, output and any external battery cables to the UPS be housed in properly grounded, metal conduits or that shielded cables be used.
UPS must be removed. All wiring must be placed in proper conduits, and all cabling must be strain relieved per local and national codes. See Table 4, “Cable Sizes,” on page 12. ONEAC Sinergy SE II Series UPS User Manual...
Page 13
7. If UPS is to be operated as single unit connect a jumper between S1 and S2. See Figure 8. 8. If UPS is to be operated as parallel unit ensure that no jumper is connected between S1 and S2. Fig. 8: Terminal Block ONEAC Sinergy SE II Series UPS User Manual...
Ports for Parallel Operation Maintenance Bypass Switch Fans Input Circuit Breaker for Main Input Input Circuit breaker for Bypass Input External Battery Receptacle Input and Output Terminal Block Fig. 9: Rear View ONEAC Sinergy SE II Series UPS User Manual...
(inputs and outputs) with 6 mm cable torqued to 2.5 nt-m; and 10kVA model (inputs and outputs) should be wired with 10 mm cable torqued to 2.5 nt-m. (Based on 90°C cable and ambient of 40°C) ONEAC Sinergy SE II Series UPS User Manual...
100 V (50 A for 6 kVA model and 83 A for 10 kVA model). However, each terminal can supply only 1/2 of the total current and both terminals MUST be connected to the load in order to provide full power. ONEAC Sinergy SE II Series UPS User Manual...
NEC. NOTE: Once the battery cabinets are physically connected to the UPS, the operator will need to configure the battery string following set-up menu table on page 21. ONEAC Sinergy SE II Series UPS User Manual...
After return of the mains voltage, the UPS automatically restores power to the connected equipment. Fig. 11: Block Diagram (120/208/240 Volt output)– Typical for models with A in the part number ONEAC Sinergy SE II Series UPS User Manual...
Page 19
UPS Operation Fig. 12: Block Diagram (120/208/230/240 Volt output)–Typical for models with I in the part number ONEAC Sinergy SE II Series UPS User Manual...
Page 20
UPS Operation Fig. 13: Block Diagram (100/200 Volt output)–Typical for models with J in the part number ONEAC Sinergy SE II Series UPS User Manual...
•Do not give command to switch off the UPS or to switch from “Online” to Flashing LEDs: “Bypass” in this status, as this would interrupt the operation of the connected critical load. ONEAC Sinergy SE II Series UPS User Manual...
Battery Test Period Battery Test Setup Menu Manual/Auto Test DC Start UPS Address Series Number Language Event and Time Logging Menu Clear Event Log About Menu Fig. 15: System Block (Main and Sub-Menus) ONEAC Sinergy SE II Series UPS User Manual...
Control Cancel Batt Test Menu No Test In Progress Test In Progress Manual Battery Test Test OK! Test Fail Battery Test Report Test Inhibit Test Stop By User Test Autonomy Test Unknown ONEAC Sinergy SE II Series UPS User Manual...
Page 24
Description Event and Time* Logging Clear Event Log Menu NOTE: * Maximum four fault event records. Window Description VXXXXX & Date (UPS Version & Date) About DSP Version XXXXX (Software Version) Menu ONEAC Sinergy SE II Series UPS User Manual...
Call technical support Batt. Disconnect Check battery connector Charger failure Call technical support RPO activated Correct problem, restart UPS Parallel fault Call technical support Internal fault Call technical support Output failure Call technical support ONEAC Sinergy SE II Series UPS User Manual...
Maintenance 1. Press the “MENU” button. Bypass Procedure 2. Select submenu “Control.” 3. Press “OK.” 4. Select submenu “Turn UPS ON/OFF.” 5. Press “OK.” The control panel displays “Turn UPS to BYPASS.” ONEAC Sinergy SE II Series UPS User Manual...
9. Press “OK.” The control panel displays “Turn UPS to ONLINE.” 10. Press “OK” to switch on the inverter. The green “ON” LED is illuminated. The UPS is now in ONLINE operation. ONEAC Sinergy SE II Series UPS User Manual...
The RPO circuit may be physically extended by connecting normally closed switches in series between the RPO connector pins. Activating (opening) any of the series switches will cause the UPS to shut off its output. ONEAC Sinergy SE II Series UPS User Manual...
“Troubleshooting” on page 31. If the test is successful, restore the UPS mains supply. The UPS is ready for operation. NOTE: The batteries must be recharged before the complete emergency supply period is again available. ONEAC Sinergy SE II Series UPS User Manual...
The UPS does not require maintenance by the user, however, battery maintenance in recommended in accordance with IEEE Recommended Practice for Maintenance, Testing and Replacement of Valve-Regulated Lead-Acid (VRLA) Batteries for Stationary Applications (IEEE Std 1188-1996). When ONEAC Sinergy SE II Series UPS User Manual...
1. Go to http://connectivity.chloridepower.com/mopexpress 2. Complete the on line registration form. 3. Download MopUPS Express. 4. Run Setup, following the screen prompts for installation. Other communication software packages and interface cables are available as options. ONEAC Sinergy SE II Series UPS User Manual...
The interface slot COM can be fitted with various optional interface cards. Optional interface cards include: • SNMP-adapter (ManageUPS ) for connecting the UPS to a network, • Isolated contacts card. Installation instructions are included with each card. ONEAC Sinergy SE II Series UPS User Manual...
This output provides an N/O contact between pins 2 and 5. The 2-5 contact closes when one of the alarms “AC FAIL,” “LOW BATT” or “BYPASS ACTIVE” is active or when the indication “ALARM” at the front-panel is on. ONEAC Sinergy SE II Series UPS User Manual...
Interface on the PC is being used by accessing the interface on the PC; try another process or is defective. selecting a different serial interface. Interference on the data cable. Lay cable differently. Reinstall cabling. ONEAC Sinergy SE II Series UPS User Manual...
Page 35
Except as set forth herein and except as to title, there are no warranties, express or implied, or any affirmations of fact or promises by ONEAC for the products, their merchantability, or fitness for any particular purpose. In no event shall ONEAC be liable for lost profits, goodwill or any other special or consequential damages.
Page 36
Warranty ONEAC Sinergy SE II Series UPS User Manual...
Appendix A: Features and Specifications Appendix A: Your ONEAC Sinergy SE II Series UPS features an on-line double conversion integrated isolation transformer. This provides the highest level of protection from power line disturbances available. Features and • Two-year warranty on power control systems Specifications...
Page 38
FCC part 15, class A, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4 EN61000-4-5 Overvoltage Category category II Optional ten foot power cord available (4 kVA - 10’ power cord with L6-30P; 6 kVA - 10’ power cord with 6-50P). Call ONEAC for details, ONEAC Sinergy SE II Series UPS User Manual...
UPS module (configuration: half load, two module parallel system) • If the systems load is greater, another UPS must be added to provide the additional capacity. Fig. 18: Typical Parallel Set Up ONEAC Sinergy SE II Series UPS User Manual...
Page 41
Appendix B: Paralleling UPS Devices Fig. 19: Paralleling Sinergy (models with A in the part numbers) ONEAC Sinergy SE II Series UPS User Manual...
Page 42
Appendix B: Paralleling UPS Devices Fig. 20: Paralleling Sinergy (models with I in the part number) ONEAC Sinergy SE II Series UPS User Manual...
2. Connect the input terminals (per the “Connecting Power Cables” on page 10) from each of the UPSs terminal blocks to the mains distribution. 3. Connect the output terminals (per “Output Terminal Voltage” on page 13) together from each of the UPSs to the load distribution. ONEAC Sinergy SE II Series UPS User Manual...
Page 44
NOTE: After a few seconds, the “BYPASS” LEDs on UPSs will extinguish and all “ON” LED’s will illuminate simultaneously, indicating that all parallel UPS inverters are running. The total load is spread evenly across all UPSs. ONEAC Sinergy SE II Series UPS User Manual...
