ON Series m
UPS
Introduction
Technical
Support
ON Series m UPS User Instruction Manual
Please read and save these instructions. This manual
contains important instructions for the ON Series m
UPS family. Follow these instructions during the
unpacking, installation and maintenance of the
Uninterruptible Power Supply (UPS) and batteries.
If you have a problem with the UPS, please refer to
this manual before calling Technical Services. The
Troubleshooting Section starting on page 16
addresses most UPS-related issues.
Thank you for selecting this uninterruptible power
supply (UPS). ONEAC's ON Series offers the most
reliable protection from the harmful effects of
electrical line disturbances for your computing and
communications equipment. ONEAC's ISO 9001
certification represents our commitment to building
world-class products. We take pride in every unit that
leaves our manufacturing facility
®
ONEAC
offers 24-hour technical support. To
contact ONEAC Technical Services:
• North America: (800) 327-8801 (opt. 3) or
(847) 816-6000 (opt. 3)
• Europe: +44 (0) 2380 610311
• email: ts@oneac.com.
NOTE: All calls received before 7 a.m. or after 7p.m.
Central Standard Time are forwarded to a cell
phone. An ONEAC Technical Support Representative
will return your call within one half hour between 5
p.m. and 10 p.m. Central Standard Time. Except for
emergencies, calls received between 10 p.m. and 7
a.m. will be returned during normal business hours.
Please check with ONEAC Technical Services
before attempting to repair or return any ONEAC
product. If an ONEAC unit needs repair or
replacement, ONEAC Technical Services issues a
Return Material Authorization (RMA) number along
with instructions on how to return the unit.
ON Series m UPS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONm 300 I and is the answer not in the manual?

Questions and answers

Summary of Contents for ONEAC ONm 300 I

  • Page 1 Troubleshooting Section starting on page 16 addresses most UPS-related issues. Introduction Thank you for selecting this uninterruptible power supply (UPS). ONEAC’s ON Series offers the most reliable protection from the harmful effects of electrical line disturbances for your computing and communications equipment. ONEAC’s ISO 9001 certification represents our commitment to building...
  • Page 2 Safety Safety Class 1 equipment Equipment not suitable for use in the presence of a FLAMMABLE ANESTHETIC MIXTURE WITH AIR or WITH OXYGEN OR NITROUS OXIDE. Not designed, intended or authorized for use in systems intended to support or sustain life. For more details on life critical applications please refer to full disclaimer in Appendix A: Warranty on page 18 at the end of this manual.
  • Page 3 230 V 50/60 Hz with IEC connectors to facilitate country-specific connector compatibility or NEMA 5-15R receptacles on the “A” models. An optically isolated communications interface is standard. Your ONEAC ON Series m UPS features full output isolation and power conditioning with Virtual Kelvin ® Ground output filtering.
  • Page 4: Unpacking And Inspection

    The table below shows the frequency settings as shipped from the factory. Table 1. Frequency Settings Model From Factory Adjustable To ONm 300 I, ONm 600 I 50 Hz 60 Hz ONm 300 J, ONm 600 J 60 Hz 50 Hz...
  • Page 5 For additional runtime, some ON Series m UPSs can Battery Enclosure(s) use extra batteries housed in a separate enclosure. Use only ONEAC model ONMXBC-217. The UPS power module and battery enclosure(s) are shipped separately. 1. Connect the battery cable from the closest battery enclosure to the external battery receptacle on the UPS, see fig.
  • Page 6 Installation 2. Connect the battery cable from the next external battery enclosure (if any) to the external battery receptacle on the battery enclosure connected in the previous step. Repeat step 2 to connect additional external battery enclosures. fig. 2: ON Series UPS and External Battery Connections Connections Before beginning, shut down and unplug the equipment to be protected.
  • Page 7 UPS. If more than one device will be connected to the UPS, use additional IEC 320 (M/F) cords as shown in figure 4. Contact ONEAC for additional IEC 320 (M/F) cords if needed. ON Series m UPS User Instruction Manual...
  • Page 8 UPS. 2. Use IEC 320 (M/F) cord(s) to connect the device(s) to the UPS IEC 320 (F) output connectors. Contact ONEAC Technical Support if your equipment does not have a detachable IEC 320 power cord. UPS to Power Source...
  • Page 9: Power Switch

    Operating Instructions Operating With the UPS connected to a properly wired AC input power source, toggle the power switch to the Instructions ( | ) “ON” position. Power is immediately supplied to the output connectors. Power Switch Toggling the power switch to the( ) “standby”...
  • Page 10: Low Battery

    Operating Instructions Low Battery When the battery voltage falls to a predetermined value, the audible alarm will sound continuously and the green and yellow LEDs will blink. If the UPS continues to operate in this mode for two minutes or more, the UPS will shutdown and remove power from the output connectors.
  • Page 11: Communications (Factory Installed Options)

    Operating Instructions inverter. If blinking, it indicates no battery, overload or high line and no battery present. Table 2. System Code Status Chart Power Battery Fault Unit Status ON/AC Present ON AC/No Battery ON AC/Battery Charging ON AC/Replace Battery ON AC/Overload ON Battery Power ON Battery/Battery Low Off/Overload...
  • Page 12: Replacing Battery(Ies)

    ONm 300 ONm 600 fig. 8: ON Series m UPS Rear Panel Replacing NOTE: To obtain new battery(ies), contact ONEAC Technical Services at (847) 816-6000, or toll free at Battery(ies) (800)-327-8801, ext. 3. In Europe, dial +44 (0) 1235 534721.
  • Page 13 Replacing Battery(ies) Procedures 1. Lay the UPS on its right side. 2. Open the battery access door on the bottom by removing the two (2) Phillips head screws at the front. Retain the screws for use in step 8 later. 3.
  • Page 14 Replacing Battery(ies) current environmental regulations. See Battery Disposal, below, if you would like ONEAC to dispose of battery. ON Series m UPS Battery Wires Battery fig. 9: ON Series m UPS Battery Replacement Replacing External For additional runtime, some ON Series m UPSs can use extra batteries housed in a separate enclosure.
  • Page 15: Battery Disposal

    3 or in Europe at +44 (0) 1235 534721 for an RMA number. Mark the RMA number on the packing slip and shipping carton. 2. Phone ONEAC Corporation for the number of a local battery collection site (US only). 3. Make arrangements with a local auto shop that collects automotive batteries for reprocessing.
  • Page 16: Troubleshooting

    You can access these numbers on the back panel of the unit on a label located near the receptacles. Always check with ONEAC Technical Services before attempting to repair or return any ONEAC product. ON Series m UPS User Instruction Manual...
  • Page 17 Troubleshooting If you have questions or problems regarding you ON Series m UPS, refer to the troubleshooting table below. Table 4. Troubleshooting Problem Possible Cause Solution Front Panel Switch not Switch the Power Switch to (I) “ON”. Reduce the load on the UPS by UPS will not turn ON UPS’s input circuit unplugging the load and press...
  • Page 18 ONEAC’s option, any defective component, circuit board, or module contained within the product only when it is returned with an ONEAC Return Material Authorization (RMA) number to ONEAC or to an ONEAC-designated repair facility. In all cases, the...
  • Page 19: Limitations Of Warranty

    Except as set forth herein and except as to title, there are no warranties, express or implied, or any affirmations of fact or promises by ONEAC for the products, their merchantability, or fitness for any particular purpose. In no event shall ONEAC be liable for lost profits, goodwill or any other special or...
  • Page 20: Appendix B: Typical Runtime

    Appendix B: Typical Runtime Appendix B: Typical Runtime Table 5. Typical Runtime by System Load Typical Runtime by System ONm300 A, I and J Models ONm300D A, I and J Models Load One 12V, 7AH Battery Two 12V, 7AH Batteries VA LOAD RUNTIME (HOURS:MINUTES) 75 VA...
  • Page 21 Appendix C: Specifications and Characteristics Appendix C: Specifications and Characteristics Table 7. Physical/Electrical Specifications and Performance Characteristics* Specification and Characteristics ONm300J ONm600J ONm300I ONm600I ONm300A ONm600A 300/200 600/400 300/200 600/400 300/200 600/400 Maximum Load - VA/Watts Load Power Factor Range UPS .65 to 1.0 (3) - will support loads rated 0.5 to 1.0 Crest Factor <3...
  • Page 22: Appendix C: Specifications And Characteristics

    Appendix C: Specifications and Characteristics Table 7. Physical/Electrical Specifications and Performance Characteristics* (Continued) Specification and Characteristics ONm300J ONm600J ONm300I ONm600I ONm300A ONm600A Output Type opto-isolated open collector transistor Input Type opto isolator input diode with anti-parallel diode and 500 ohms in series Table continued on next page Minimum Input to Activate Shutdown (mA)
  • Page 23 Appendix C: Specifications and Characteristics Table 8. Physical/Electrical Specifications and Performance Characteristics for ONMXBC-217 External Battery Specifications and ONMXBC-217 Characteristics Voltage 2x 12 V Current 40 A Batteries two at 12 V, 17 AH Operating Temperature 0º to +40ºC (32 to 104ºF) Storage Temperature -15 to 45ºC (+5 to 113ºF) Relative Humidity...
  • Page 24 Appendix C: Specifications and Characteristics Safety & Approvals Table 9. Emissions Test Regulations Emissions Test Regulations United States 47 CFR Part 15 Subpart B:1999 Canada Interference-Causing Equipment Standard (ICES-003 Issue 2, Rev.1) Europe EMC-Directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC EN 50091-2 / 09.95 (UPS Equipment) EN 50081-1 / 01.92 (Generic Emission - Residential, Commercial and Light Industrial)
  • Page 25 Appendix C: Specifications and Characteristics Table 10. Immunity Test Regulations Immunity Test Regulations Europe EMC-Directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC EN 50091-2 / 09.95 (UPS Equipment) EN 50082-1/08.97 (Generic Immunity - Residential, Commercial and Light Industrial) EN 60601-1-2 / 05.93 (Medical equipment) EN 61000-4-2 / 03.95 (IEC 1000-4-2 / 01.95) EN 61000-4-3 / 1995 (IEC 1000-4-3 / 02.95) ENV 50204 / 03.95...
