CHIEF PRO-2000 Series Installation Instructions Manual

I N S T A L L A T I O N I N S T R U C T I O N S
Large Flat Panel Wall Mount
Model: PRO-2000 Series

PRO-2000 Series Wall Mount Features:

• Accommodates large flat screens weighing up to
200 lbs (90.7 kg).
• Mounting brackets adapt to either 16" or 24" on
center dual stud wood framework; integrated
lateral shift adjusts ± 4.5" (16" on center) or ± 0.5"
(24" on center).
• Infinite tilt and lock adjustment between 0-15
degrees.
• Chief's exclusive Q-Latch mounting system
provides convenient and secure display connect/
disconnect; optional padlock provides additional
display security.
®
Q-Latch is a registered trademark of Chief Mfg.
! IMPORTANT: If the installation of this product requires
OSHPD seismic approval, refer to OSHPD pre-approval
documents and drawings before beginning installation.
OSHPD documents and drawings are available at
www.chiefmfg.com, and are also located on the product
information page for the mount.

BEFORE YOU BEGIN

CAUTION: To prevent damage to your monitor and PRO-2000, which could affect or void the Factory warranty,
thoroughly study all instructions and illustrations before you begin to install the mount. Pay particular attention to the
Warnings and Cautions in this document.
• The mount is designed to be installed using wall studs or supporting framework. The fasteners used to anchor
the mount must be capable of supporting five times the total weight of the equipment.
• The maximum weight to be installed on the PRO-2000 wall mount is 200 lbs (90.7 kg).
• If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-582-
6480.
