CHIEF PACCC1 Installation Instructions Manual

Center channel speaker mounting accessory

Advertisement

Quick Links

I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Center Channel Speaker Mounting Accessory
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
PACCC1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PACCC1 and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF PACCC1

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Center Channel Speaker Mounting Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PACCC1...
  • Page 2 It is the serious injury or death if you do not follow the instructions. installer’s responsibility to make sure the combined weight of all components attached to the PACCC1 does not exceed 35 lbs (16 kg). 15.86 14.00"...
  • Page 3 Installation Instructions PACCC1 LEGEND Tighten Fastener Adjust Apretar elemento de fijación Ajustar Befestigungsteil festziehen Einstellen Apertar fixador Ajustar Serrare il fissaggio Regolare Bevestiging vastdraaien Afstellen Serrez les fixations Ajuster Loosen Fastener Security Wrench Aflojar elemento de fijación Llave de seguridad Befestigungsteil lösen...
  • Page 4 PACCC1 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/8" (Provided) PARTS C (1) [left upright] A (1) [right upright] B (1) [center plate] D (4) G (6) F (2) E (4) [mounting button] 10-24 x 1/2" 10-24 10-24 x 7/8" J (1) H (5) 1/8"...
  • Page 5: Assembly And Installation

    1/8" hex wrench (J). (See Figure 3) IMPORTANT ! : When installing the PACCC1 to the PACLR1, the uprights shipped with the PACCC1 will NOT be used as the uprights already installed on the PACLR1 are identical.
  • Page 6 PACCC1 Installation Instructions Install Accessory to Mount and Display to Accessory Install accessory to mount following the installation instructions provided with the mount. (See Figure 5) (J) x1 Figure 3 Mount speaker to speaker mounting bracket following the instructions provided with speaker. (See Figure 4)
  • Page 7 The PACCC1 allows for vertical adjustment of the speaker to provide a flush installation against the bottom of the display. The PACCC1 also provides up to 10 deg of YAW adjustment for proper speaker alignment with bottom of display. To adjust speaker vertical position: Loosen two button head cap screws securing speaker mounting bracket to support plate using 1/8"...
  • Page 8 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a products division F +31 (0)40 2668615 of Milestone AV Technologies Asia Pacific A Office No. 1 on 12/F, Shatin Galleria...
