Using your Favourite Editing Software
37
Adobe Premiere Pro
Capture

Adobe Premiere Pro CS6

Setting up a Blackmagic Design project
Step 1. Launch Premiere Pro.
Step 2. Create a New Project and click on the Scratch Disks tab.
Step 3. Set the desired Location and Name for your project at the bottom of this window.
Step 4. Set the locations for your captured video, captured audio, video previews and audio previews.
Step 5. Set the Capture Format to Blackmagic Capture and click on the Settings button to reveal the
Blackmagic Capture Settings for your project. The Video Standard can be set to NTSC, PAL,
HD720 or HD1080. The Video Format can be uncompressed or compressed. Now click OK.
Step 6. The New Sequence window will appear. To preserve maximum video quality, you'll need to create
a full resolution uncompressed sequence. To do so, click the discovery triangle next to "Blackmagic
Design", select a preset to match the video standard and choose from uncompressed 8 bit YUV,
10 bit YUV or 10 bit RGB. If you don't have the storage space or disk speed for uncompressed
video, choose a JPEG sequence preset for a full resolution, open-standard codec.
When you have selected the desired sequence preset, give the sequence a name and click OK.
Capturing Live via Thunderbolt
To capture video live via Thunderbolt from HyperDeck Studio Pro:
Step 1. Choose: File > Capture [F5]
Step 2. Press play on HyperDeck Studio Pro and then Click the red record button [G]. A preview of the
video you are capturing will appear.
To change the capture format, click on the Settings tab and then the Edit button. Ensure the Capture Format
is set to Blackmagic Capture, click on the Settings button and then change the Blackmagic Capture Settings
as desired.
