Using your Favourite Editing Software

33

Editing with HyperDeck Studio Pro

When connected to a computer with Thunderbolt technology, HyperDeck Studio Pro can be used as a
powerful capture solution for your editing workflow. The HyperDeck Installer software installs Blackmagic
System Preferences which allow your favorite video editing software to perform live capture from HyperDeck
Studio Pro via Thunderbolt.
Video Capture
Remember to set the project preferences in your video capture software to match the video format playing
back from HyperDeck Studio Pro.
Once you have correctly configured the project preferences and set your application to capture, video will
appear on your computer screen within a few seconds.
If you still can't see an image in your video capture software, quit out of the software and launch Blackmagic
UltraScope. Make a note of the output video standard which is displayed on the left side of Ultrascope's
Picture Display. Quit UltraScope, launch your video capture software and set the project preferences to
match the standard reported by UltraScope.

Using Blackmagic System Preferences

Blackmagic system preferences provide a central location so you don't need to configure the same software
settings in each video application that you use.
On Mac OS X, open the System Preferences and click the Blackmagic Design icon. When using HyperDeck
Studio Pro, settings are grayed out and the main use of the Blackmagic system preferences is to tell you which
version of Desktop Video software is installed for video capture via a Thunderbolt port.
When other Blackmagic video capture hardware is connected to your computer, additional settings may
be available.
Blackmagic Design system preferences in Mac OS X
