Using HyperDeck Shuttle

25

HyperDeck Shuttle Controls

Buttons
1. Record
HyperDeck Shuttle will instantly record the moment you press
the Record button, even if you're playing back a clip. This
means you'll never miss a good take that's happening. If the
button flashes red, the SSD is too slow and cannot keep up
with recording.
2. Previous Clip
If you hold down the Previous Clip, the clip will reverse at
2x speed. Pressing the button again will increase the speed
to 4x and 8x. If you want to resume playing back at normal
speed, just press the Play button. Or you can press the Stop
button to pause when reversing.
3. Stop
The Stop button also switches HyperDeck Shuttle between
playback and video loop through mode.
4. Play
When a clip is playing, pressing Play again will loop it
continuously.
1 2 3 4 5
DISP
5. Next Clip
If you hold down Next Clip, the clip will fast forward at 2x
speed. Pressing the button again will increase the speed to
4x and 8x. If you want to resume playing back at normal
speed, just press the Play button. Or you can also press the
Stop button to pause when fast forwarding.
6. DISP
This button isn't currently used but will soon be enabled by a
software update. You will be able to download this for free at
www.blackmagicdesign.com
7. Power On/Off
The Power button turns the HyperDeck Shuttle on or off. To
prevent someone from accidentally switching off the unit,
you must hold the Power button down for 2 seconds to turn
it off. If you're running off the built-in batteries, the unit will
turn itself off to conserve power after 8 minutes if you're not
recording.
6 7 8 9 10
VIDEO
Status Indicators
8. VIDEO
The VIDEO indicator lights up when a video signal is detected
by HyperDeck Shuttle.
9. SSD
The SSD indicator lights up in green when it is accessing a
correctly formatted SSD. If the SSD has not been formatted
correctly, or fails to work, the SSD light will illuminate solid
red until the SSD is removed.
10. Battery
The four green battery indicators display the internal battery
charge level. When all the LEDs go off, there's approximately
4 minutes of battery power left. So you should plug in
your external power source or switch to another charged
HyperDeck Shuttle.
