Avid Media Composer 6.X - Blackmagicdesign HyperDeck Shuttle Installation And Operation Manual

Using your Favourite Editing Software
34
Media Composer
Step 5. Type a project name and set the project options.

Avid Media Composer 6.x

Avid Media Composer captures standard and high definition video live from HyperDeck Studio Pro via a
Thunderbolt cable. Blackmagic plug-ins for Media Composer are automatically installed if Media Composer
is installed before the Desktop Video software.
You can use the INPUT button on HyperDeck Studio Pro to select your video and audio connections
including SDI, analog and HDMI.
Setting up
Step 1. Launch Media Composer and the Select Project dialog box will appear.
Step 2. Choose your preferred User Profile if you have previously created one.
Step 3. Select the folder in which you want to create the project: Private, Shared or External.
Step 4. Click the New Project button.
Step 5. Type a project name and set the project options including Format and Color Space. Click OK.
Once the project has been created, the frame rate and raster cannot be changed. The color
space setting can be changed later in the Format tab of the project.
Step 6. Double-click the project name in the Select Project dialog box. The Media Composer interface
will appear along with the project window for your new project. You have completed setting up
your project.
