Using HyperDeck as a Disk Recorder
18
The LCD on HyperDeck Studio models displays embedded
SDI timecode during playback when the option to "Play back
media timecode track to SDI output" is switched on.
Playing Back RP 188 Embedded Timecode
If you use HyperDeck Utility to switch on the option to "Play back media timecode track to SDI output"
when playing back high definition video, your HyperDeck will embed SMPTE RP 188 metadata allowing
other video equipment to display or record the timecode.
Timecode is also commonly displayed on HD-SDI monitors but you will often need to find a menu setting
to turn it on. The LCD on HyperDeck Studio models also displays the RP 188 timecode during playback.
Looping Playback
HyperDeck Shuttle - Press the play button when a clip is playing to initiate loop mode. Loop mode will
continue until you press stop.
HyperDeck Studio models - Enable loop mode during playback by pressing the play button. The display
will show if loop mode is on or off.
Shuttling with HyperDeck Shuttle
If you're reviewing a long clip and need to quickly shuttle to a particular section, just hold down the Previous
Clip or Next Clip button. This will allow you to reverse or fast forward through the clip at 2x speed. To go
faster, press the Previous Clip or Next Clip button again and the speed will increase to 4x and then 8x. Once
you've found the section you want to review, press Play and playback will resume at normal speed.
Jog and Shuttle with HyperDeck Studio Models
If you're reviewing a long clip and need to quickly shuttle to a particular section, press the reverse or fast
forward button to play through the clip at 2x speed. To go faster, press the reverse or fast forward button
again and the speed will increase to 4x and then 8x. Once you've found the section you want to review, press
play to resume normal playback.
You can also use the Jog/Shuttle Wheel to shuttle to a particular section at variable speeds. The more you
turn it forwards or backwards, the faster your HyperDeck Studio will play through your video. Once you've
found the section you want to review, press play to resume normal playback.
If you want to slowly jog through your video, frame by frame, press the JOG button once to enable jog
operation. Turning the jog/shuttle wheel in the desired direction will then jog through your video. Pressing
the JOG button again will return the wheel to shuttle operation.
