Using HyperDeck as a Disk Recorder
24
RS-422 Developer Information
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Byte 9
Variables
Cassette Out
Local
Standby
Direction
Still
Auto Mode
Select EE, Full EE
Lamp Still/Fwd/Rev
Near EOT
EOT
Others
Cue Complete (byte 2, bit 0)
Bit 7 Bit 6 Bit 5
0 0 Cassette out
Standby 0 Stop
Servo Lock 0 Shuttle
Auto Mode 0 0
Select EE Full EE 0
0 0 0
0 Lamp Still Lamp Fwd
0 0 0
0 0 Near EOT
0 0 0
Set if no SSD is present
Set if Remote is disabled (local control)
Set if a disk is available
Clear if playback is forwarding, set if playback is reversing
Set if playback is paused, or if in input preview mode
Set if in Auto Mode
Set if in input preview mode
Set according to playback speed and direction
Set if total space left on available SSDs is less than 3 minutes
Set if total space left on available SSDs is less than 30 seconds
Always 1: Cue requests are always instantaneous
Bit 4 Bit 3 Bit 2
0 0 0
0 Rewind Forward
Jog Var Direction
0 Aout Set Ain Set
0 0 0
0 0 0
Lamp Rev 0 0
0 0 0
EOT 0 0
0 0 0
HyperDeck Serial RS-422 Protocol
Protocol
Interface
Bit 1 Bit 0
0 Local
Record Play
Still 1
Out Set In Set
0 0
0 0
0 0
0 0
0 0
0 0
Based on Sony 9-pin protocol
Baud rate 38.4 kBits/s
1 start bit
8 data bits
1 stop bit
1 parity bit
Odd parity
