Specifications
Display
Display Accuracy
Voltage Output, DC
Current Output, DC
Ripple and Noise
Line Regulation
Load Regulation
Efficiency
Power Factor
Operating %RH
Altitude
Installation Category
Pollution degree
Power
Supply voltage fluctuation
Dimensions
Weight
Dual 4-digit LED
±(1% + 15 counts)
0.0 to 16.40V,
0.10 to 27.60V,
0.100 to 5.100A, 0.100 to 3.100A, 0.1 to 2.00A
<30mVp-p
< 4mV/<10mA
< 20mV/<10mA
>75%
>0.9
10 to 80% RH
2000m
CAT 2
2
90 to 264VAC (47 to 63Hz)
± 10% of stated operating voltage
13 x 5 x 2" (330 x 127 x 53.5mm) (DxHxW)
4.2lbs. (1.9 kg)
6
0.10 to 36.80
382260-EN V1.5 7/12
