Specifications - NEC MultiSync LCD1550ME Service Manual

Specifications

Monitor Specifications
LCD Module Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Display Colours Analog input:
Synchronization Range Horizontal:
Viewing Angle Left/Right:
Up/Down:
Resolutions Supported
Active Display Horizontal:
Area
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
Speakers Practical Audio Output
MultiSync LCD1550ME Monitor
38 cm/15 inches
38 cm/15 inches
1024 x 768
Video:
ANALOG 0.7 Vp-p/75 Ohms
Sync:
Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
16,777,216
31.5 kHz to 60.0 kHz
56.2 Hz to 75.1 Hz
Vertical:
± 60°
+ 45°/- 55°
720 x 400* 1 :VGA text
640 x 480* 1 at 60 Hz to 75 Hz
1
800 x 600* at 56 Hz to 75 Hz
1
832 x 624* at 75 Hz
2
1024 x 768* at 60 Hz to 75 Hz
304 mm/12 inches
Vertical:
228 mm/9.0 inches
AC 100-120 V/220-240 V 50/60 Hz
0.7 A @ 100-120 V, 0.35 A @ 220-240 V
345.2 mm (W) x 362.6 mm (H) x 162.0 mm (D)
13.6 inches (W) x 14.3 inches (H) x 6.4 inches (D)
3.9 kg (8.6 lbs)
5 °C to 35 °C
30% to 80%
Humidity:
0 to 3,000 m
Altitude:
-10 °C to +60 °C
Humidity: 10% to 85%
0 to 9,500 m
Altitude:
1.0W + 1.0W
English-19
1-20
Notes
Active matrix; thin film
transistor (TFT) liquid
crystal display (LCD);
0.30 mm dot pitch;
2
250cd/m white luminence,
typical; 400:1 contrast ratio,
typical.
Depends on display card
used.
Automatically
Automatically
Some systems may not
support all modes listed.
Dependent upon signal
timing.
