Specifications

Monitor
Specifications
Picture Tube
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and vertical
frequencies only
Active Display Area
(Factory setting)
Active Display Area
(Full scan)
Power Supply
Current Rating
Dimensions
Weight
Enviromental Considerations
Operating Temperature:
Storrage Temperature:
100
95
NOTE: Technical specifications are subject to change without notice.
75
25
5
0
All manuals and user guides at all-guides.com
MultiSync FE750
Monitor
Diagonal: 43 cm (17 inch)
Viewable Image Size: 41 cm (16 inch)
Radius: 50000 mm
ANALOG 0.7 Vp-p/75 Ω
Video:
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 92 kHz
Vertical: 55 Hz to 160 Hz
640 x 480 @ 60 to 160 Hz
800 x 600 @ 55 to 141 Hz
832 x 624 @ 55 to 136 Hz
1024 x 768 @ 55 to 112 Hz . . . . . . . . . . . . . . . . . .
1152 x 870 @ 55 to 99 Hz
1280 x 1024 @ 55 to 85 Hz
1600 x 1200 @ 55 to 73 Hz
Horizontal: 315 mm
Vertical: 236 mm
325 mm
243 mm
AC 100-120 V / 220-240 V, 50/60 Hz
1.1 A @ 100-120 V / 0.5 A @ 220-240 V
403 (W) x 427 (H) x 424 (D) mm
20.0 kg
+10° C to +35° C
Humidity: 30% to 80%
Altitude: 0 to 3000 m
-20° C to +60° C
Humidity: 10% to 90%
Altitude: 0 to 13700 m
E - 11
Notes
90° deflection, 0.25 mm grille pitch, medium short
persistence phosphor, aperture grille CRT,
multi-layered, anti-static screen coating, dark tint
screen and OptiClear screen surface.
Depends on the display card
Automatically
Automatically
Some systems may not support all modes listed
NEC cites recommended resolution at 85 Hz for
optimal display performance.
Dependent upon signal timing used, and does not
include border area.
Dependent upon signal timing used, and does not
include border area.
