REPLACEMENT PARTS LIST

The components specified for Model LCD1550ME(B)
SYMBOL
*** ICS ***
I001 79PL1440
I301 79PL1948
I302 79PL1951
I303 79PL1950
I304 79PL1447
I305 79PL1949
I306 79PL1323
I308 79PL2046
I309 79PL1322
I310 79PL1441
I801 79PL1439
I802 79PL1438
I803 79PL1437
*** TRANSISTORS ***
Q301 79PL1321
Q302 79PL1321
Q303 79PL1435
Q304 79PL1036
Q305 79PL1037
Q306 79PL1036
Q307 79PL1036
Q308 79PL1436
Q309 79PL1436
Q310 79PL1037
Q311 79PL1036
Q312 79PL1436
Q313 79PL1436
Q803 79PL2058
Q806 79PL2069
*** DIODES ***
D301 79PL1947
D304 79PL1947
D305 79PL1144
D306 79PL1947
D307 79PL1144
D308 79PL1947
D309 79PL1144
D310 79PL1249
D311 79PL1249
PART NO
IC TDA7496L 20P PDIP SG
IC-M51953AFP-8P-SOP
IC-MTV312MV64-44P-PLCC-MY
IC-TTL-NC7SZ04M5X-5P-FAIR
IC 24LC32A 8P SOP MICROCH
IC-TTL-NC7SZ08M5X-5P-FAIR
IC GMZAN1 160P PQFP GENES
IC-CPU-24LC024-8PIN-SOIC-
IC LM358DT 8P SOP ST
IC AIC1084 33CM 3P TO26
IC KA3842AE S 8P PDIP F
IC LTV 817D 4P PDIP LIT
IC KA431AZ 3PIN TO-92 T
TR NPN SST2222A 800MA/50V
TR NPN SST2222A 800MA/50V
FET P-CHNL SI2305DS VISHA
TR NPN SST3904 SMD
TR PNP 2SA1037AK T146/R
TR NPN SST3904 SMD
TR NPN SST3904 SMD
FET N&P-CHNL 2SK3018 ROHM
FET N&P-CHNL 2SK3018 ROHM
TR PNP 2SA1037AK T146/R
TR NPN SST3904 SMD
FET N&P-CHNL 2SK3018 ROHM
FET N&P-CHNL 2SK3018 ROHM
FET-N-CHNL-SSS4N60AS-2.3A
TRANSISTOR-PNP-2SA733P-T-
DIODE-MM4148-SMD-GOODARK
DIODE-MM4148-SMD-GOODARK
DIODE ZNR RLZ TE-11 5.6B
DIODE-MM4148-SMD-GOODARK
DIODE ZNR RLZ TE-11 5.6B
DIODE-MM4148-SMD-GOODARK
DIODE ZNR RLZ TE-11 5.6B
DIODE DAN217 T146 SMD3
DIODE DAN217 T146 SMD3
8-1
DESCRIPTION
