Summary of Contents for NEC MultiSync LCD1550M
- Page 1 MultiSync LCD1550M User’s Manual...
- Page 2 If a power cord is not supplied with this equipment please contact your supplier. When operating the MultiSync LCD1550M with a 220-240V AC power source in Australia, use the power cord provided with the monitor.
- Page 3 – EN 55022 – EN 61000-3-2 – EN 61000-3-3 – EN 55024 and marked with NEC-Mitsubishi Electric Visual Systems, Corp. MS Shibaura Bldg., 13-23, Shibaura 4-chome, Minato-Ku, Tokyo 108-0023, Japan Power consumption of the monitor is less than 3W when in power-saving mode.
-
Page 4: Canadian Department Of Communications Compliance Statement
Ce produit porte la marque ‘C-UL’ et se conforme aux règlements de sûrele Canadiens selon CAN/CSA C22.2 No. 950. FCC Information 1. Use the attached specified cables with the MultiSync LCD1550M colour monitor so as not to interfere with radio and television reception. -
Page 5: Declaration Of Conformity
1250 N. Arlington Heights Road Itasca, Illinois 60143-1248 Tel. No.: (630)467-3000 Type of Product: Computer Monitor Equipment Classification: Class B Peripheral Models: MultiSync LCD1550M We hereby declare that the equipment specified above conforms to the technical standards as specified in the FCC Rules. English-4... - Page 6 Contents Your new NEC MultiSync LCD monitor box* should contain the following: • MultiSync LCD1550M monitor with tilt/swivel base • Power Cord(s) • Video Signal Cable • Audio Cable • USB Cable • User’s Manual • CD ROM (includes complete User’s Manual in PDF format). To see the User’s Manual, Acrobat Reader 4.0 must be installed on your PC.
-
Page 7: Quick Start
For Mac: Connect the MultiSync LCD1550M Macintosh cable adapter to the computer (Figure C.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to the MultiSync LCD1550M Macintosh cable adapter (Figure C.1). Tighten all screws. 4. Connect the 15-pin mini D-SUB of the video signal cable to the appropriate connector on the back of the monitor (Figure D.1). - Page 8 8. The Vacation Switch on the left side of the monitor must be turned on (Figure H.1). Turn on the monitor with the Power Button and the computer. NOTE: The Vacation Switch is a true on/off switch. If this switch is on the OFF position, the monitor cannot be turned on using the front button DO NOT switch on/off repeatedly.
-
Page 9: Figure G
Connector cover Cable cover Clip B Figure D.1 Figure E.1 Figure F.1 A Type B Type Figure G.1 English-8... -
Page 10: Tilt And Swivel
Vacation Switch Power Button Figure H.1 Tilt and Swivel Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel as desired (Figure TS.1). Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1. - Page 11 Figure TS.1 Figure R.1 Figure R.2 Non-abrasive surface English-10...
- Page 12 Figure R.3 7. This LCD monitor is designed for use with a flexible arm. Please use the attached screws (4pcs) when mounting. To meet the safety requirements the monitor must be mounted to an arm which guaranties the necessary stability under consideration of the weight of the monitor.
-
Page 13: English
Controls OSM (On-Screen-Manager) Controls The OSM controls on the front of the monitor function as follows: To access OSM press any of the control buttons ( , , -, +, NEXT). Control Menu EXIT Exits the OSM controls. Exits to the OSM main menu. Moves the highlighted area left/right to select control CONTROL / menus. -
Page 14: Auto Adjust
CONTRAST Adjusts the image brightness in relation to the background. AUTO ADJUST Adjusts the image displayed for non-standard video inputs. Auto Adjust Automatically adjusts the Image Position, the H. Size and Fine setting. Position Controls LEFT/RIGHT Controls Horizontal Image Position within the display area of the LCD. - Page 15 sRGB sRGB mode dramatically improves the colour fidelity in the desktop environment by a single standard RGB colour space. With this colour supported environment, the operator could easily and confidently communicate colours without further colour management overhead in the most common situations. NATIVE Original colour presented by the LCD panel that is unadjustable.
- Page 16 FACTORY PRESET Selecting Factory Preset allows you to reset all OSM control settings back to the factory settings. The RESET button will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting the control to be reset and pressing the RESET button.
-
Page 17: Recommended Use
Recommended Use Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE MULTISYNC LCD COLOUR MONITOR: • DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. - Page 18 • Allow adequate ventilation around the monitor so that heat can properly dissipate. Do not block ventilated openings or place the monitor near a radiator or other heat sources. Do not put anything on top of monitor. CAUTION • The power cable connector is the primary means of detaching the system from the power supply.
- Page 19 • Avoid displaying fixed patterns on the monitor for long periods of time to avoid image persistence (after-image effects). • Get regular eye checkups. Ergonomics To realize the maximum ergonomics benefits, we recommend the following: • Use the preset Size and Position controls with standard signals. •...
-
Page 20: Specifications
Specifications Monitor Specifications Notes MultiSync LCD1550M Monitor LCD Module Diagonal: Active matrix; thin film 38 cm/15 inches transistor (TFT) liquid Viewable Image Size: 38 cm/15 inches crystal display (LCD); Native Resolution (Pixel Count): 1024 x 768 0.30 mm dot pitch;... - Page 21 *2 NEC-Mitsubishi Electronics Display cites recommended resolutions at 75 Hz for optimal display performance. NOTE: Technical specifications are subject to change without notice.
- Page 22 Features sRGB Colour Control: A new optimized colour management standard which allows for colour matching on computer displays and other peripherals. The sRGB, which is based on the calibrated colour space, allows for optimal colour representation and backward compatibility with other common colour standards.
- Page 23 FullScan Capability: Allows you to use the entire screen area in most resolutions, significantly expanding image size. VESA Standard Mounting Interface: Allows users to connect their MultiSync monitor to any VESA standard (75 mm pitch) third party mounting arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant device.
-
Page 24: Troubleshooting
“ghost” of that image remains, the monitor should be turned off for one hour to erase the image. NOTE: As with all personal display devices, NEC-Mitsubishi Electronic Displays recommends using a screen saver at regular intervals whenever the screen is idle. - Page 25 Image is unstable, unfocused or swimming is apparent • Signal cable should be completely attached to the computer. • Use the OSM Image Adjust controls to focus and adjust display by increasing or decreasing the fine total. When the display mode is changed, the OSM Image Adjust settings may need to be readjusted.
-
Page 26: No Sound
No Sound • Check to see if speaker cable is properly connected. • Check to see if mute is activated. • Check to see if volume in OSM is set at minimum. USB Hub does not operate • Check to make sure the USB cord is properly connected. Refer to your USB device User’s Manual. - Page 27 TCO’99 This is a translation of the original English TCO'99 document. MultiSync LCD1550M white Model (LA-15R03) Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed...
- Page 28 The requirements cover a wide range of issues: environment, ergonomics, usability, emission of electrical and magnetic fields, energy consumption and electrical and fire safety. The environmental demands concern restrictions on the presence and use of heavy metals, brominated and chlorinated flame retardants, CFCs (freons) and chlorinated solvents, among other things.
- Page 29 Cadmium** Cadmium is present in rechargeable batteries and in the colourgenerating layers of certain computer displays. Cadmium damages the nervous system and is toxic in high doses. TCO’99 requirement states that batteries, the colourgenerating layers of display screens and the electrical or electronics components must not contain any cadmium.
- Page 30 TCO’95 This is a translation of the original English TCO'95 document. MultiSync LCD1550M Black Model (LA-15R03-BK) Congratulations! You have just purchased a TCO’95 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also...
- Page 31 The environmental demands concern restrictions on the presence and use of heavy metals, brominated and chlorinated flame retardants, CFCs (freons) and chlorinated solvents, among other things. The product must be prepared for recycling and the manufacturer is obliged to have an environmental plan which must be adhered to in each country where the company implements its operational policy.
- Page 32 Cadmium** Cadmium is present in rechargeable batteries and in the colourgenerating layers of certain computer displays. Cadmium damages the nervous system and is toxic in high doses. TCO’95 requirement states that batteries may not contain more than 25 ppm (parts per million) of cadmium. The colourgenerating layers of display screens must not contain any cadmium.
