Figure 2: VP-4x1CS 4x1 PC Graphics Clean Switcher Rear Panel

#
1
AUDIO IN1~IN4 Unbalanced Stereo Audio 3.5mm Mini Jacks
2
PC VIDEO IN1~IN4 UXGA 15-pin HD Connectors (F)
3
PC OUT UXGA 15-pin HD Connector (F)
4
ETHERNET RJ-45 Connector
5
RS-232 Serial Port 9-pin D-sub Connector (F)
6
REMOTE IR Opening
7
Mains Power Connector, Fuse and Power Switch
8
AUDIO OUT Unbalanced Stereo Audio 3.5mm Mini Jack
9
AUDIO OUT Balanced Stereo Audio 5-pin Terminal Block
10
RESET Button
11
REMOTE Contact Closure Selector and Mute Switches 6-way
Terminal Block
Feature
Connect to up to 4 unbalanced, stereo audio sources
Connect to up to 4 PC graphics sources
Connect to the PC graphics acceptor
Connect to a PC via a LAN to control the device (see
Connect to a PC/serial controller (see
Connect to an external IR receiver for controlling the device using an IR
remote controller (see
Section
4.1)
Plug in the power cord and switch the device on and off
Connect to the unbalanced, stereo audio acceptor (see
Connect to the balanced, stereo audio acceptor
Press and hold while powering on to reset the device to factory default (see
Section
4.1)
Connect pins 1 to 4 and G to up to 4 remote, input selector, contact closure
switches. Connect the OFF and G pins to a remote mute switch (see
Section
6.1)
Function
Section
6.4)
Section
6.3)
Section
6.2)
