- Page 1 PECTRA YNAMICS, 1 PPS P ULSE ISTRIBUTION MPLIFIER PPS-2RM-B1 PERATING ANUAL PECTRA YNAMICS, NC • 1849 Cherry St. Unit 2. • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088 www.spectradynamics.com...
- Page 3 Description The PPS-2RM-B1 Instrument is a 1 pulse-per-second (1 PPS) generator. The 1 PPS is generated from a sine-wave input signal. The input signal can be a 1 MHz, 5 MHz or 10 MHz signal. The PPS-2RM-B1 contains two modules. Each module provides two outputs of 1 PPS.
-
Page 4: Safety And Preparation For Use
Line Voltage This instrument may be setup to operate on 100-120 or 220-240 VAC and a line frequency of 50 to 60 Hz. The setup voltage for this PPS-2RM-B1 is specified on page 4. Fuse A 0.50 Ampere 250V slow-blow fuse is used for 100-120 VAC operation. -
Page 5: The Front Panel
One pulse per second outputs. These outputs provide a 2 volt peak-to- peak signal into a 50 ohm load. PPS LED The LED will flash on the rising edge of the 1 PPS output signal from the 1 PPS generator module. Copyright © SpectraDynamics, Inc. 2010... -
Page 6: The Back Panel
The Back Panel The Back Panel AC POWER ENTRY MODULE The PPS-2RM-B1 is configured to operate on: 100-120 VAC 220-240 VAC DC POWER ENTRY MODULE Optional Battery Backup Connector for +24 VDC Backup power source. Copyright © SpectraDynamics, Inc. 2010... -
Page 7: Battery Backup Module
If your PPS-2RM-B1 includes the battery backup module, this module will allow the PPS-2RM-B1 instrument to be powered by a 24 VDC power source in case of loss of the main AC power. The switch from AC to DC supply operation is affected by a Schottky diode network and charge storage capacitors to ensure glitch free operation. - Page 8 Pin 2 GND (Internal supply voltage for monitoring purpose do not use !) Pin 3 -V (Internal supply voltage for monitoring purpose do not use !) Pin 4 24 VDC GND return Pin 5 +24 VDC power Pin 6 Chassis GND /Earth GND Copyright © SpectraDynamics, Inc. 2010...
-
Page 9: Reference Frequency
Reference Frequency Reference Frequency Configuration The PPS-2RM-B1 pulse generator can be configured to operate on 1 MHz, 5 MHz or 10 MHz references. The default configuration for the unit is 5 MHz. To change the reference frequency the unit must be unplugged from the power source. Do not remove the bottom cover of the unit. -
Page 10: Operation
PPS input. It is important to turn off the synchronization enable switch by moving it to the down position to disable further inadvertent synchronization events. Copyright © SpectraDynamics, Inc. 2010... -
Page 11: Specifications
Input Signal Level 1 MHz, 5 MHz and 10 MHz External Sync. Error 1 MHz +/- 500 5 MHz +/- 100 10 MHz +/- 50 Temperature-delay 0 - 50 ºC ps/ºC Coefficient 25 - 35 ºC Copyright © SpectraDynamics, Inc. 2010... -
Page 12: Warranty
SDI’s option, any product not meeting the said specifications. This warranty shall be in effect for one (1) year from the date a PPS-2RM-B1 is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose. - Page 13 PPS-2RM-B1:2x1PPS/R02...
