- Page 1 PECTRADYNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA15-RM-C PERATING ANUAL PECTRADYNAMICS, NC • 1849 Cherry St. Unit 2. • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088...
- Page 2 HPDA15-RM-C Description The HPDA15-RM-C is a high performance distribution and isolation amplifier. It contains 3 modules each of which provide 5 unity gain outputs for every input signal. Typical cross channel isolation is 125 dB and reverse isolation is typically greater than 135 dB.
-
Page 3: Safety And Preparation For Use
Service Do not attempt to service or adjust the instrument unless another person, capable of providing first aid or resuscitation, is present. Contact SDI for any questions or repairs. Operation To operate the unit, locate the AC power entry connector on the rear panel and connect the power cable. -
Page 4: The Front Panel
The Front Panel The Front Panel AC Power LED The LED is on when AC power is applied to unit and the unit is operating properly. DC Power LED The LED is on when DC power is applied to unit and the unit is operating properly. Monitor LED The LED will turn on if the input signal to the corresponding channel is greater than +7 dBm. -
Page 5: The Back Panel
The Back Panel The Back Panel AC POWER ENTRY MODULE The HPDA15-RM-C is configured to operate on 100 to 120 VAC. DC POWER ENTRY CONNECTOR Optional Battery Backup Connector for +24 VDC Backup power source. SMA INPUTS There are 3 amplifier modules each having one input and 5 outputs. The signal to be distributed should be connected to the SMA jack labeled input. -
Page 6: Battery Backup Module
Battery Backup Module Description The battery backup module allows the HPDA15-RM-C instrument to be powered by a 24 VDC power source in case of loss of the main AC power. The switch from AC to DC supply operation is effected by a schottky diode network and charge storage capacitors to ensure glitch free operation. - Page 7 DC Connector WARNING! DO NOT APPLY AC VOLTAGE TO THIS UNIT THROUGH THE 6 PIN CONNECTOR ON THE REAR OF THE UNIT! Failure to follow these directions will cause injury or death to personnel, cause irreparable damage to the instrument and void all warranties.
-
Page 8: Operation
This unit is designed to operate only with a 100 to 120 VAC power source. For conversion to a different voltage of operation contact SDI. To operate the unit, locate the power entry module on the rear of the enclosure and connect the power cord. -
Page 9: Specifications
Specifications HPDA Module Specifications PARAMETER CONDITIONS UNITS Max. Input Power 1 dB compression Bandwidth +/- 1 dB 1 - 20 Gain @ 5 MHz +/- 0.5 Impedance input Ohms output Return Loss input(S11) 5MHz output(S22) 5MHz Distortion* +13 dBm +16 dBm Isolation output to output output to input... -
Page 10: Warranty
SpectraDynamics, Inc (SDI). SDI’s obligation and liability under this warranty is expressly limited to repairing or replacing, at SDI’s option, any product not meeting the said specifications. This warranty shall be in effect for one (1) year from the date an HPDA-15RM-C is sold by SDI. - Page 11 Frequency Doubler Module An optional high performance frequency doubler module may be added to the HPDA15-RM-C. The input frequency in MHz must be specified upon ordering. The input level should be between +12 and +15 dBm. Lower input level ranges may be specified when ordering the unit.
