- Page 1 PECTRA YNAMICS, ERFORMANCE ISTRIBUTION MPLIFIER HPDA-100RM-C PERATING ANUAL PECTRADYNAMICS, NC • 1849 Cherry St. Unit 2 • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088 www.spectradynamics.com...
- Page 2 HPDA-100RM-C Description The HPDA-100RM-C is a high performance distribution and isolation amplifier. It contains 2 modules that provides ten unity gain outputs. Typical cross channel isolation and reverse isolation is typically greater than 100 dB. The phase noise of the modules is exceptionally low, typically –145 dBc/Hz @ Fourier frequency of 1 Hz and –173 dBc/Hz...
-
Page 3: Safety And Preparation For Use
To operate the unit, locate the AC power entry connector on the rear panel and connect the power cable. When power is applied to the unit, a red led located on the front panel, labeled “on”, should light up. Copyright © SpectraDynamics, Inc. 2005... -
Page 4: The Front Panel
The LED is on when DC power is applied to unit and the unit is operating properly. Monitor LED The LED will turn on if the input signal to the corresponding module is greater than +7 dBm. Copyright © SpectraDynamics, Inc. 2005... -
Page 5: The Back Panel
The Back Panel The Back Panel AC POWER ENTRY MODULE The HPDA-100RM-C is configured to operate on 100 to 120 VAC. DC POWER ENTRY CONNECTOR Optional Battery Backup Connector for +24 VDC Backup power source SMA INPUTS There is one SMA input. The signal to be distributed should be connected to the SMA jack labeled input. -
Page 6: Battery Backup Module
Battery Backup Module Description The battery backup module allows the HPDA-100RM-C instrument to be powered by a 24 VDC power source in case of loss of the main AC power. The switch from AC to DC supply operation is effected by a schottky diode network and charge storage capacitors to ensure glitch free operation. - Page 7 Pin 2 GND (Internal supply voltage for monitoring purpose do not use !) Pin 3 -V (Internal supply voltage for monitoring purpose do not use !) Pin 4 24VDC GND return Pin 5 +24VDC power Pin 6 Chassis GND /Earth GND Copyright © SpectraDynamics, Inc. 2005...
-
Page 8: Operation
“POWER” will turn on. Attach the signal to be distributed to one of the SMA input connectors on the front panel. Any HPDA-100 output may be used to drive the input of another distribution module. Copyright © SpectraDynamics, Inc. 2005... -
Page 9: Specifications
Phase Noise 10 Hz -158 -155 dBc/Hz 100 Hz -165 -162 1 kHz -171 -168 10 kHz -174 -171 All tests done at 100 MHz and +13 dBm input unless otherwise specified. Copyright © SpectraDynamics, Inc. 2005... -
Page 10: Warranty
This warranty shall be in effect for one (1) year from the date an HPDA-100RM-C is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose. SDI’s obligation under this warranty shall not include any transportation charges or costs of installation or any liability for direct, indirect, or consequential damages or delay.
