NIBP Test

Warning
A blood pressure cuff, connected to the monitor, should never be
applied to a human subject while the monitor is in Diagnostic
Mode. Injury could result.
Power-up Defaults Menu And Diagnostic Mode
A/D Channel Designators
A1
ECG
RWAVE
PACEMAKER
TEMP 1 (93° TO 112°)
PRESSURE XDUCER 1
PRESSURE XDUCER 2
NiBP OSCILLATORY
ECG LEAD OFF
TEMP 2 (59° TO 93°)
ISOLATED VOLTAGE REF
ISOLATED VOLTAGE ZERO
SpO
S1 S018
2
(BATTERY VOLTAGE) X 0.5
TEMP PROBE <=0=ORAL,
1=RECTAL, 2=CAL KEY,
>=3 NONE)
+3.3 VDC POWER SUPPLY
(NiBP VOLTAGE REF) X 0.5
GROUND REFERENCE
(+5 VDC POWER SUPPLY) X 0.5
ADC MID-SCALE VALUE
ADC ZERO-SCALE VALUE
ADC FULL-SCALE VALUE
A3
1.
ECG
2.
RWAVE
3.
PACEMAKER
4.
RESPIRATION
5.
PRESSURE XDUCER 1
6.
PRESSURE XDUCER 2
7.
NiBP OSCILLATORY
8.
ECG LEAD OFF
9.
TEMPERATURE
10.
ISOLATED VOLTAGE REF
11.
ISOLATED VOLTAGE ZERO
SpO
S1 S018
2
12.
(BATTERY VOLTAGE) X 0.5
13.
NOT USED
14.
+3.3 VDC POWER SUPPLY
15.
(+12 VDC POWER SUPPLY) X
0.33
16.
(NiBP VOLTAGE REF) X 0.8
17.
GROUND REFERENCE
18.
(+5 VDC POWER SUPPLY) X 0.8
19.
ADC MID-SCALE VALUE
20.
ADC ZERO-SCALE VALUE
21.
ADC FULL-SCALE VALUE
Diagnostic Mode
43
