Summary of Contents for Stelpro SK series
- Page 1 User’s guide ‘‘SK’’ series Ceiling fan heater Replacement component list included This unit complies with the CSA and UL standards For further information or to consult this guide on line, please visit our Web site. INSSK0610...
- Page 2 If an option must be added, make sure it has been approved by Stelpro. This way, it will ensure that it has been tested in accordance with our safety rules and that an appropriate installation has been planned into the unit.
-
Page 3: Specifications
SPECIFICATIONS CEILING FAN HEATER MODEL SKII VOLTS 120, 208, 240, 277 V 277, 347 V WATTS 500 to 2000 W 1000 to 2000 W WEIGHT 11 lb / 5 kg 14 lb / 6.4 kg DEPTH 4 3/8’’ / 111 mm 6 3/8’’... -
Page 4: New Construction
1. The longer side of the unit 2. The longer side of the unit 3. The longer side of the unit resting perpendicular to the resting parallel to the ceiling resting parallel to the ceiling joists. joists. (When you have access ceiling joists. - Page 5 RECESSED INSTALLATION INTO A SUSpENDED CEILING Within the current suspended ceiling tile Within the T-bar adapter (optional) 1. Remove a tile where you want to install the unit and cut on an opening 1. Fix the unit directly to the T-bar adapter (optional) by screwing the within it (see dimensions hereinafter).
-
Page 6: Electrical Connection
SURFACE INSTALLATION (with an optional surface adapter) Finished ceiling Suspended ceiling To the T-Bar 1. Screw the surface adapter (op- To the suspended ceiling tile adapter (optional) tional) to the ceiling (4 screws), making sure the joist will support 1. Insert the surface adapter 1. - Page 7 REPLACEMENT COMPONENT LIST # diagram # part Description # diagram # part Description ELF-SK001 ELEMENT (KIT) 500 W-120 V / 2000 W-240 V / 1500 W-208 V ELF-SK017 ELEMENT (KIT) 500 W-208 V ELF-SK002 ELEMENT (KIT) 500 W-240 V ELF-SK018 ELEMENT (KIT) 1000 W-208 V ELF-SK003 ELEMENT (KIT) 1000 W-240 V / 750 W-208 V...
-
Page 8: Limited Warranty
The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original war- ranty period.
