USER'S GUIDE
SIRH SERIES
INFRARED RADIATOR HEATER
RADIATEUR INFRAROUGE
INFRARED RADIATOR
SIRH1501W* - SIRH2002W* - SIRH4002W* -
SIRH4203W* - SIRH6002W* MODELS
*Add R for the weather-resistant model
For further information or to consult this guide online, please visit our web site: www.stelpro.com
REPLACEMENT COMPONENT LIST INCLUDED
This unit
complies with
CSA standards
INSSIRH0117
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stelpro ZENITH SIRH1501W Series
Summary of Contents for Stelpro ZENITH SIRH1501W Series
- Page 1 INFRARED RADIATOR SIRH1501W* - SIRH2002W* - SIRH4002W* - SIRH4203W* - SIRH6002W* MODELS This unit *Add R for the weather-resistant model complies with CSA standards For further information or to consult this guide online, please visit our web site: www.stelpro.com INSSIRH0117...
-
Page 2: Specifications
AVERTISSEMENT Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this product. -
Page 3: Technical Drawings
TECHNICAL DRAWINGS 1500 W + 2000 W MODELS 4000 W MODEL 21 1/4" 540mm 12 1/4" 311mm 14 15/16" 380mm 21 5/8" 5 5/8" 550mm 143mm 19" 2 11/16" 483mm 69mm 2 5/8" 66mm 15 7/8" 403mm 7 15/16" 202mm SIDE FRONT 4180 W + 6000 W MODELS... -
Page 4: Installation
SHOULD BE RESPECTED WHEN INSTALLING THE INFRARED RADIATORS: - Unit must be horizontally mounted. - If the support provided is not sufficient for the clearance distance required, Stelpro offers an optional extensible support (product code: KIT-SIRH-SUP1) which can be adjusted to obtain distances ranging from 20 in. -
Page 5: Electrical Connections
4000 W / 3200 W AT 240 V / 208 V & 4200 W AT 347 V UNITS It is very important to respect the clearance from flammable material, as mentioned below. INSTALLATION MURALE INSTALLATION AU PLAFOND WALL INSTALLATION CEILING INSTALLATION minimum minimum 12"... -
Page 6: Maintenance
REPLACEMENT OF AN INFRARED LAMP Handle carefully; there are sharp aluminum pieces inside. 1. Before installing or replacing an infrared lamp, switch off the appropriate circuit breaker in the electrical service panel. 2. Remove the back cover (1). 3. Before disconnecting the defective lamp, please note how the wires are fixed to the ceramic terminal blocks. - Page 7 REPLACEMENT COMPONENT LIST REF. # PART # DESCRIPTION M-SIRH100ABK Assembled case for SIRH2002W* model M-SIRH200ABK Assembled case for SIRH4002W* model M-SIRH300ABK Assembled case for SIRH4203W* and SIRH6002W* model M-SIRH105ZBK Back cover with louvers (SIRH2002W) M-SIRH113ZBK Back cover without louvers (SIRH2002WR) M-SIRH205ZBK Back cover with louvers (SIRH4002W) M-SIRHRP205ZBK...
-
Page 8: Limited Warranty
Stelpro reserves the right to examine or to ask one of its representatives to examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a defective part.
