A: Technical Specifications
32
Table A-2 lists physical, thermal, power, and compliance specifications for C2005 servers. The
numbers reflect a typical configuration with four hot-swap drives.
Table A-2 Physical, Thermal, Power, and Compliance Specifications
Attribute
Form
Dimensions
Gross weight
Max. thermal sustained
output
Actual max. power number
Power supply
Compliance
Specification
2U rack mount / half-depth (14.5")
3.5" x 17.6" x 15.5" (HxWxD)
~27lbs.
1121BTU/hr (AC) and 839BTU/hr (DC)
(approximate, based on a typical configuration)
346W (AC) and 256W (DC)
(approximate, based on a typical configuration)
Input: 100–240VAC (standard), –48VDC (optional)
250W or 450W with +3.3V, +5V, +12V, –5V, and –12V main DC
outputs and a 5V standby
US (FCC, CFR47 Part 15, Class )
Canada (ICES Class A)
Europe (CE, EN55022 & EN55024)
Australia (C-TICK)
Japan (VCCI)
