1: Overview
4
Table 1-1
Configuration Options
Attribute
Chassis Profile
Processors
Max. Cores
Chipset
Front Side Bus Speed
Memory*
Hard Disk Drives
Max. Capacity
RAID Card Levels
(optional)
Expansion Cards
Networking, Onboard*
Roamer Remote Mgmt.
Card/LCD (optional)
IPMI Remote System*
Management (optional)
Power Supply
Intel-based C2005
2U half-depth
Up to two identical dual-core
processors from the following:
– Intel Xeon 5500 or 5600 Series
– Intel Xeon E-5 2600 Series
– Intel Xeon E-5 2600v2 Series
12
Intel 5400 or 5500
Up to 1600MHz
Up to 288GB (18 x 16GB DIMMs);
max speed of 1333 Mhz
Up to five 3.5", ten 2.5" hot-swap
SAS or SATA II drives or a
combination of both
SAS/SATA 3.5" HDDs: 15TB
SAS/SATA 2.5" HDDs: 10TB
RAID 0, 1, 5, 6, 10, 50, 60*
Up to five PCI Express low-profile
slots or one slot on a riser*
Up to 4GigE
Serial or IP + Keyboard, Video and
Mouse (KVM)
IPMI 2.0
Auto-switching 100–240 VAC or
–48 VDC, optional redundant
power supply (AC 650W)
AMD-based C2005
2U half-depth
Up to two multi-core AMD
Opteron 4100 or 61xx Series
processors
32
NVIDIA nForce Pro 3600
N/A
Up to 256GB (16 x 16GB DIMMs);
max speed of 1600 Mhz
Up to five 3.5", ten 2.5" hot-swap
SAS or SATA II drives or a
combination of both
SAS/SATA 3.5" HDDs: 15TB
SAS/SATA 2.5" HDDs: 10TB
RAID 0, 1, 5, 6, 10, 50, 60*
Up to five PCI Express low-profile
slots or one slot on a riser*
Up to 4GigE
Serial or IP + Keyboard, Video and
Mouse (KVM)
IPMI 2.0
Auto-switching 100–240 VAC or
–48 VDC, optional redundant
power supply (AC 650W)
007-5717-002
