1: Overview
10
Table 1-3 Front Panel Components (continued)
Component Description
LED indicator lights These LEDs provide you with critical information related
to different parts of the system.
Green (PWR): The LED farthest to the left indicates that
power is applied to the server and the system is on. When
the LED is off, the system is off, even if the AC power
cord is plugged into the server.
Blue (HDD): The LED in the middle indicates that the
hard drive(s) are currently being accessed and activity is
occurring.
Red/Tri-color (ID2): The LED to the far right may have
several functions depending on the configuration of your
server. If your server was purchased with the Roamer
remote management module, then this LED can be turned
on or set to blink via Roamer so that a technician can
easily identify a unit that may need service.
Power button This single-push, push button is a power on/off button.
When the system is in an off state, pushing the button once
powers the system on. When the system is in an on state,
pushing and releasing the button power the system off.
This button does not have a reset function.
Power supply AC: Connect only 100-240 Volt AC, 3A or 5A maximum,
connector 50-60 Hz. Use a standard AC connector to connect power
to the server. An AC power cord is included in your
documentation and accessory kit.
DC: Connect only.
Power switch This power switch turns the server on and off. It controls
the power supply that is inside the chassis.
