4 Pin Main Harness
3 Pin Parking Light Harness
6 Pin Start Harness
1
2
3
4
5
6
4 Pin Alternate Output Harness
1
2
3
4
2 Pin Lock Output Harness
4
PURPLE
RED
ORANGE
PINK/WHITE
RED/WHITE
PINK
LT GREEN/BLACK
LT BLUE
GREEN/WHITE
BLACK/YELLOW
STARTER OUTPUT - MOTOR SIDE
BATTERY 12V ( + )
ACCESSORY 1 ( + )
IGNITION 2 ( + )
BATTERY 12V ( + )
IGNITION 1 ( + )
FACTORY DISARM / PULSE BEFORE START ( - )
FACTORY ARM / PULSE AFTER START ( - )
PULSE AFTER SHUTDOWN ( - )
PULSE DURING CRANK ( - )
2010 Audiovox Electronics Corporation. All rights reserved.
