8 Pin Main Harness

1
WHITE/RED
2
WHITE
Locate the parking light output wire at the vehicle's light switch.
Verification: This wire registers positive voltage when the parking lights
are turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
3
BLACK
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point is a metal surface
in the driver's side kick panel area.
NOTE: Do not ground the BLACK wire with any other vehicle components.
4
ORANGE
This wire will have a continuous ( - ) 200mA output when the system is Armed. This
wire is typically used for controlling window modules or additional sensors.
2009 Audiovox Electronics Corporation. All rights reserved.
PARKING LIGHT INPUT
PARKING LIGHT OUTPUT
GROUND
GROUND WHEN ARMED OUTPUT ( - )
