5 Pin Main Harness

1 WHITE/RED
2 WHITE
Locate the parking light output wire at the vehicle's light switch.
Verification: This wire registers positive voltage when the parking lights
are turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
3 BLACK
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point is a metal surface in
the driver's side kick panel area.
NOTE: Do not ground the BLACK wire with any other vehicle components.
4 BROWN
This output is available to be used as a constant ( + ) siren output OR a pulsed
( - ) horn output and is selectable by changing the jumper position on the main
module. Refer to the system layout on page 22 for location.
SIREN:
Connect the BLACK siren wire to a chassis ground using a ring terminal and self
tapping screw (not supplied).
Route the BROWN siren output wire from the control module through the firewall and
connect to the RED wire on the siren.
NOTE: Be sure to loom the siren wires, and seal the grommet.
