PROFESSIONAL
SERIES
Remote Start
Installation Guide
ca 4552
ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ca 4552 and is the answer not in the manual?

Questions and answers

Summary of Contents for Code Alarm ca 4552

  • Page 1 PROFESSIONAL SERIES Remote Start Installation Guide ca 4552 ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 2: Table Of Contents

    Tach Programming .................. 14 Smart Tachless Mode ................14 Feature Descriptions ................15 Transmitter Button Functions ............. 18 2 Way Transmitter Notifications ............18 Remote Start Shutdown Diagnostics ..........19 System Layout ..................20 ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 3: Before You Begin

    Use a Digital Multi Meter for testing and verifying circuits. DO NOT USE A TEST LIGHT, OR "COMPUTER SAFE PROBE" as these can set off air bags or damage vehicle computers. Technical Support (800) 421-3209 or go to http://techservices.codesystems.com ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 4: Wire Connection Guide

    FACTORY DISARM / PULSE BEFORE START ( - ) LT BLUE FACTORY ARM / PULSE AFTER START ( - ) GREEN/WHITE PULSE AFTER SHUTDOWN ( - ) BLACK/YELLOW PULSE DURING CRANK ( - ) 2 Pin Lock Output Harness ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 5: Pin Main Harness

    Jump To PINK BLUE/BLACK Active Output Accessory Output Wire Ignition Output Wire Wire From Wire From Control Module Control Module To Vehicle's 2nd or 3rd Accessory Wire To Vehicle's 2nd or 3rd Ignition Wire ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 6 Locate the vehicle’s brake light wire at the brake pedal mounted switch. This connection is required for Remote Start. Verification: This wire registers positive voltage when the brake pedal is pressed. Connect the BROWN/RED wire to the vehicle’s brake light wire. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 7: Pin Parking Light Harness

    Connect the WHITE wire to the parking light output wire. Negative switching Parking Lights: Connect the WHITE/RED wire to a good chassis ground. Connect the WHITE wire to the parking light output wire. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 8: Pin Start Harness

    RUN) position, but not the ACC (Accessory) position. The voltage does not drop out when the key is turned to the START (or CRANK) position. Connect the PINK/WHITE wire to the vehicle’s ignition 2 wire. Programmable output: IGN, ACC, Start. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 9: Pin Alternate Output Harness

    This wire will supply a ( - ) 500mA pulse upon successful completion of the remote start activation sequence and is typically used to re-lock the vehicle’s doors upon remote start if necessary. This output is configurable in option programming. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 10: Pin Door Lock Output Harness

    To Vehicle's 2nd S tarter W ire 2 Pin Lock Output Harness BLUE UNLOCK ( - ) The door unlock output wire provides an output only while the remote start feature is active. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 11: Additional Ports

    This 4 pin port is used for Telematic Interface accessories, such as the CarLink ASCL1, which can control some of the following features. Door Unlock Control Trunk Release Sliding Doors AUX Output Car Find Remote Start ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 12: Set Up & Programming

    NOTE: The system will remain in feature programming mode as long as the ignition is on, there is no time limit. To exit programming turn the IGNITION OFF. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 13: Programming Feature Banks

    Running Crank Lock Pulse After Ground While Pulse During 3 Green / White Output Ignition Accessory Shutdown Running Crank Pulse During Ground While 4 Black / Yellow Output Ignition Accessory Crank Running ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 14: Tach Programming

    Within the 7 flash time period, press and hold the button. One extended parking light flash (1.5 seconds) will indicate the system is now in tachless mode. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 15: Feature Descriptions

    Hybrid (Crank Average / No Voltage) - Determines crank time by averaging the last 8 times the vehicle was started with the key. DBI Port - Monitors the vehicle’s tach rate through an interface module connected to the DBI port. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 16 Start / Crank - Crank output during remote start. 11 - 2 or 3 Hour Start: When activated, the remote start will activate and run for the programmed time and shut down every 2 or 3 hours. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 17 Accessory - Output becomes active with the same timing as the accessory output, drops out during crank. Pulse During Crank - Output becomes active with the same timing as the starter output wire, during crank only. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 18: Transmitter Button Functions

    4 Beeps / Flashes (repeats for 10 seconds) Remote Start Running 1 Flash per second for duration run time Remote Start Shutdown 1 Long Beep / Long Flash (repeats for 10 seconds) ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 19: Remote Start Shutdown Diagnostics

    3 Flashes Hood Input Brake Input 4 Flashes Remote Start Valet Mode 5 Flashes Manual Transmission Mode not set (manual transmission models only) 7 Flashes Tach not learned / Crank Average not learned ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 20: System Layout

    2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 21 2011 Audiovox Electronics Corporation. All rights reserved.
  • Page 22 2. This device must accept any interference received, including any interference that may cause undesired operation. Warning! Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
