AC Power

To connect your phone to the network using AC power, make sure you have
the optional AC Power Kit. The AC Power Kit contains a Power Adapter,
Regional Power Cord, and a Power Insertion Cable.
The following figure shows how to connect your phone to the network using
optional AC power.
25-foot Network Cable
To connect the phone using AC power:
1. Connect one end of the 25-foot Network Cable to the LAN jack on the
phone.
2. Connect the other end of the 25-foot Network Cable to the
Power Insertion Cable.
3. Connect the Power Insertion Cable to an available LAN port on the wall
or hub/switch device port.
4. Connect the Power Adapter to the Power Insertion Cable.
5. Connect the Power Adapter (with the attached Regional Power Cord) to
the wall outlet.
Power Insertion Cable
2
4
Power Adapter
3
5
