- Page 1 For Serial Nos. 720,000 & Higher ULTRA VAC ® LAZER Z HP MODELS ® Place Model No. and Serial No. Date Purchased Label Here (Included in the Literature Pack) or Fill in Below Model No. Serial No. Part No. 4500-240 Rev. A...
- Page 2 Exmark reserves the right to make changes or add improvements to its products at any time without incurring any obligation to make such changes to products manufactured previously. Exmark, or its distributors and dealers, accept no responsibility for variations which may be...
- Page 3 (6) line items or less. 4. If order is received by 3:00 p.m. central time, Exmark ships part(s) direct to dealer or customer, as requested by distributor, same day, overnight UPS, Exmark bills the distributor for parts and shipping charges, where applicable.
-
Page 4: Introduction
Introduction CONGRATULATIONS on the purchase of your Exmark Ultra Vac. This product has been carefully designed and manufactured to give you a maximum amount of dependability and years of trouble-free operation. This manual contains operating, maintenance, adjustment, and safety instructions for your Exmark Ultra Vac. -
Page 5: Table Of Contents
Contents Introduction ............4 Safety ..............6 Safety Alert Symbol ......... 6 Safe Operating Practices ........6 Safety and Instructional Decals ....... 9 Specifications ............10 Model Numbers ..........10 Systems ............10 Dimensions........... 10 Torque Requirements ........10 Product Overview ..........11 Operation ............. -
Page 6: Safety
Preparation This symbol means: ATTENTION! BECOME • Only use on machines approved by Exmark. ALERT! YOUR SAFETY IS INVOLVED! • Wear appropriate clothing including safety glasses, substantial footwear, long trousers, and hearing protection. -
Page 7: Slope Operation
Safety Slope Operation DANGER Use Extreme caution when mowing and/or turning There are rotating blades in the blower and on slopes as loss of traction and/or tip-over could under the mower deck. Blade contact can occur. The operator is responsible for safe operation cause serious operator or bystander injury on slopes. -
Page 8: Maintenance And Storage
Safety • Remove or mark obstacles such as rocks, tree limbs, etc. from the mowing area. Tall grass can hide obstacles. • Watch for ditches, holes, rocks, dips and rises that change the operating angle, as rough terrain could overturn the machine. •... -
Page 9: Safety And Instructional Decals
Exmark equipment dealer or labels. distributor or from Exmark Mfg. Co. Inc. • Replace all worn, damaged, or missing safety • Safety signs may be affixed by peeling off the signs. -
Page 10: Specifications
Specifications Specifications Model Numbers Serial Nos: 720,000 and Higher LHPUV4448; LHPUV4650; LHPUV5256 Systems Curb Weight: 156 lb (71 kg), including the front weight. Bagging System • Collection Bins: Torque Requirements – Commercial grade, cloth mesh bags with reinforced bottoms. Bolt Location Torque –... -
Page 11: Product Overview
Operation Product Overview Operation Note: Determine the left and right sides of the machine from the normal operating position. Pre-Start Make sure you understand the controls, their locations, their functions, and their safety requirements. Ensure the blower, belt cover, bags, tube and hood are in good condition, properly attached, and latched. -
Page 12: Bagger Removal For Side Discharge
Operation 3. To remove the bags, shut off deck drive, stop the engine and wait for all moving parts to stop. Open the hood and remove the bags by lifting up on the rear of the bag, then unhooking the front clip. -
Page 13: Bagger Installation For Bagging
Operation 8. Remove the hair pins and clevis pins holding the CAUTION hood assembly to the mount weldment. The deck sheave will become very hot. 9. Lift the bag and hood assembly off the mount. Touching a hot deck sheave can cause severe 10. -
Page 14: Transporting
Operation 7. Install the belt cover using the two knobs. Install WARNING the discharge tube assembly by slipping the upper end into the hood, then sliding the lower end over Loading a unit on a trailer or truck increases the blower discharge opening. Use the latches to the possibility of backward tip-over. - Page 15 Operation ramp angle. The trailer or truck should be as level as possible. Important: Do Not attempt to turn the unit while on the ramp, you may lose control and drive off the side. Avoid sudden acceleration when driving up a ramp and sudden deceleration when backing down a ramp.
-
Page 16: Maintenance
Maintenance Maintenance Note: Determine the left and right sides of the machine from the normal operating position. WARNING WARNING While maintenance or adjustments are being The engine can become very hot. Touching made, someone could start the engine. a hot engine can cause severe burns. Accidental starting of the engine could Allow the engine to cool completely before seriously injure you or other bystanders. -
Page 17: Lubricate Grease Fittings
Maintenance Lubricate Grease Fittings Check Condition of Belt Note: See chart for service intervals. Service Interval: Every 50 hours 1. Stop engine, wait for all moving parts to stop, and 1. Stop engine, wait for all moving parts to stop, and remove key. -
Page 18: Cleaning
Maintenance Cleaning Clean Muffler and Rear Frame Area Service Interval: Before each use or daily Stop engine, wait for all moving parts to stop, and remove key. Engage parking brake. WARNING Operating engine parts, especially the muffler, become extremely hot. Severe burns can occur on contact and debris, such as leaves, grass, brush, etc. -
Page 19: Troubleshooting
Troubleshooting Troubleshooting Important: It is essential that all operator safety mechanisms be connected and in proper operating condition prior to mower use. When a problem occurs, do not overlook the simple causes. For example: starting problems could be caused by an empty fuel tank. The following table lists some of the common causes of trouble. - Page 20 No Claim of breach of warranty shall be cause for cancellation included with the product. or rescission of the contract of sale of any Exmark mower. All warranty work must be performed by an authorized Some states do not allow exclusions of incidental or...
- Page 21 Notes:...
-
Page 22: Service Record
Service Record Date: Description of Work Done: Service Done By:... - Page 24 Steerable Sulky Sulky Hitch Kit Turf Striper Standon Check Us Out On The Web: www.exmark.com © 2000–2007 Exmark Mfg. Co., Inc. Part No. 4500-240 Rev. A Industrial Park Box 808 (402) 223-6300 Beatrice, NE 68310 Fax (402) 223–5489 All Rights Reserved...
